Product Features
■
Affordable DS3 bandwidth
consolidation
■
Built-in 1:1 redundancy
■
Hot-swappable controller
cards and power
supplies
■
SNMP and Telnet management
TL1 alarming and provisioning
■
support
■
Backhaul multiple service
types (T1/E1)
■
Smallest M13 form factor
available
Dual redundant load sharing
■
DC power supplies
■
M13 and C-Bit signaling
support
Industry-standard CSU and
■
NIU loopback codes
■
NEBS Level 3 compliant
Industry-leading, 10-year
■
warranty
M13 Multiplexer
MX2810 M13 Multiplexer
Backhaul consolidation of T1 remains an
important function in network operations.
With central office space at a premium,
carriers need an M13 device that provides
cost efficiency, compact size, and built-in
intelligent redundancy. ADTRAN
applied its industry-leading expertise in
developing carrier class products to the
MX2810
TM
M13 multiplexer. The MX2810
offers bandwidth consolidation at a low price
and in the smallest footprint available in the
industry. Measuring only 1U high in 19-inch
or 23-inch rackmount configurations, this
compact device gives ILECs a powerful tool
for consolidating 28 T1 signals or 21 E1
signals into a T3 circuit.
The MX2810 houses two hot-swappable
controller cards capable of combining inde-
pendent T1s, E1s, or T1s and E1s on the same
DS3. The two controller cards also provide
built-in 1:1 redundancy for the DS1 and DS3
signals, as well as built-in BERT (Bit Error
Rate Testing) capabilities. When a T1 failure is
detected, the MX2810 will not swap to the
secondary board until it determines that the
failure is hardware-oriented and not a line
failure. This intelligent redundancy feature
minimizes unnecessary hits to the line that
has
other M13 units may allow.
®
Like all ADTRAN products, the MX2810
offers comprehensive management options,
including full management and GUI support
from ADTRAN's Total Access
a VT100 terminal interface for local configura-
tion. To support SNMP and Telnet
management, the MX2810 has an integrated
10Base-T Ethernet port. It has an RS-232 port
for network management, as well as an
RS-485 port for daisy chaining multiple units.
TL1 alarming and provisioning are also
supported.
The MX2810 meets the most stringent
NEBS Level 3 requirements. In addition, the
product is backed by an industry-leading
10-year warranty.
®
EMS. It features
