Installation Under W98 - Addi-Data APCI-8001 Commissioning Manual

30
Sub-component insertion diagram (soldered side) of the APCI-8001
Must flash when
the PC is
switched on.
Freely programmable
Freely programmable
Freely programmable

4.1.1 Installation under W98

If the board is displayed in the device manager with an exclamation mark:
- Select it with the right mouse key and select properties : Driver – Update driver. You also can delete the
wrong device in the device manager and then select "Update". Then the device is detected as a "PCI Memory
Controller". Then do the following steps:
•
Select: Show a driver list in a specific directory...
•
Select multifunction board
•
Select the floppy disc
•
Select mcug3.inf (e.g. on CD)
•
Select the correct product (e.g. APCI-8001)
•
Under Win98 the following message is displayed: "The driver is not written for the selected
hardware..." etc.
This happens because Win98 overwrites the Sub-Vendor ID of the board and therefore does not
recognize it. Confirm this message with OK.
•
Then confirm it with Yes and install it.
Now the device must be correctly registered in the device manager under "Multifunction boards".
Please note that for Windows 98 the Miniport driver V7.01b (CD sub-directory V9x) must be used.
We recommend you to use a Windows version later than Windows 9x.
M
UST
D32 D31 D30 D29 R52
+ + + +
BE
R63
R68
LIT
UP
R1
R9
12
0
J13 J20
R6
2
R6
R6
1
0
R59
.
R1
R9
06
1
CM / C
OMMISSIONING
M
UST
D28 D27
+ +
BE
R76
R67
LIT C57
R66
R70
R7
C52
5
.
C56
UP
R74
M
ANUAL
U48
U47 R51
C5
1
R69
U49
R8 R8 C7 R8 C6
9 8 0 7 8
U6
2
