3.12.7 The environment variable FBCH?

Feedback channel: An available analog input can be allocated to an analog actual value channel. This
variable is only significant for axes with motor types "ANALOG PWM" (Section 3.12.1.4), "ANALOG /
ANALOG" (Section 3.12.1.6), "CI_ANALOG" and "CD_ANALOG" (Section 3.12.1.16).
FBCHx y: x is the index of the axis to which the channel is assigned; y is the index of the analog input (0...7)
or of the common variable (0...999) that is to be read as a feedback channel. If this variable is not set, each
axis channel 0..7 is assigned the respective analog input channel 0..7.
Example:
set FBCH0 0
3.13 Special features for system parameters for servo and stepper
motor axes
Please note the system parameters listed below, which must be set accordingly in the system.dat system file
using the mcfg.exe application.
Operating mode
Servo motor
Stepper motor
What next?
If you have reached this point without any errors, the xPCI-800x controller has been successfully set up and
is ready for use. To complete the installation, you can now execute the following steps in the mcfg.exe
application:
•
[File] [Dialog Functions][Show Axis Status] to display the current position actual and setpoint values
as well as the axis status information
•
[File] [Dialog Functions][Show Digital Inputs / Status] to display the digital inputs, axis status and
interface status information
•
[File] [Dialog Functions][Edit Digital Outputs] to set or reset the digital outputs
•
[File] [Motion Tools] for manual procedure of the drive axes. In doing this, note that the [Close Loop]
button must also be activated for a stepper motor axis, before the axis can be manually operate
using the [Jog Start], [Jog Stop] or [Jog Back] buttons. This is necessary, as stepper motor axes are
also managed via an internal control algorithm.
ANUAL
Parameter/page
Motor type {mt} /
motion parameters
Encoder slits or step
pulses /
motion parameters
Motor type {mt} /
motion parameters
Encoder slits or step
pulses /
motion parameters
Filter parameter {kp} /
motor-specific
parameters
Value/meaning
Servo/operating mode selection
Slits/strokes (electronic quadrupling is considered)
Stepper/operating mode selection
Pulses/steps (no electronic quadrupling)
0.04 (is set by the system))/ any other value will
lead to instable control behaviour
Note: as of mcfg.exe version
2.5.0.45, {kp} can no longer be edited for stepper
motors. You require rwmos.elf firmware version
2.5.0.4 or later
