Analog Devices EZ-KIT Lite ADSP-BF707 System Manual page 71

A
3.3V
PROC OSC
3.3V
1
R134
10K
0402
R189
0 U36 4
0402 VDD
1
SYS_EXTWAKE STANDBY OUT
GND
25MHZ 2
OSCCC200X250
OPTIONAL PROC CRYSTAL
R136 Y1
0 25MHZ
0402 OSC013
DNP DNP
SYS_XTAL
2
C130
18PF
0402
DNP
3
RTC crystal
R195
10M
0603
R132 Y3
0 32.768KHZ
0402 OSC_ABS07L
RTC0_CLKIN
C132
15PF
0402
DNP
4
A
B
3.3V
R133
33
0402 C129
3 0.01UF
SYS_CLKIN
0402
R135
0
0402
DNP
SYS_CLKIN
C131
18PF
0402
DNP
R131
0
0402
RTC0_XTAL
C133
15PF
0402
DNP
B
3.3V
3.3V
USB OSC
R148
10K
0402
R188
0 U35 4
0402 VDD
1 3
SYS_EXTWAKE STANDBY OUT
GND
24MHZ 2
OSCCC200X250 TP20
OPTIONAL USB CRYSTAL
R146
0
0402
DNP
USB0_XTAL
BOOT MODE
3.3V
SW1
C 1
SYS_BMODE0
2
1 3
2
SYS_BMODE1
0 4
4
7 5
6
SWT027
ROTARY
R138 R139 R137
10K 10K 10K
0402 0402 0402
JP1
1 2
VDD_RTC HADC0_VIN0
3 4 HADC0_VIN1
IDC2X2_SMT
J8 J7
SMC SMC
AMPHENOL_152119 AMPHENOL_152119
HADC0_VIN3 HADC0_VIN2
AGND AGND
C
3.3V
R147
33
0402 C139
0.01UF
USB0_CLKIN
0402
Y2 R145
24MHZ 0
OSC013 0402
DNP DNP
USB0_CLKIN
C137 C138
18PF 18PF
0402 0402
DNP DNP
BOOT MODE SWITCH (SW1)
BOOT MODE (1:0)
00 No Boot
01 SPI Master Boot (SPI2) DEFAULT
10 SPI Slave Boot (SPI2)
11 UART Boot (UART0)
R140 0
PC_05/SPT0_AFS/TM0_TMR3/MSI0_CMD
0402
C134
27PF
0402
AGND
ANALOG
DEVICES
Title ADSP-BF707 EZ-BOARD
Size Board No.
C
Date
04/04/2014
C
D
1
2
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Clocks, Boot Mode
Rev
A0450-2013
1.0
Sheet of
3 13
