2.2. L26-T EVB & Kit Accessories
GNSS
Antenna
L26-T_EVB_User_Guide
Micro-USB connector
Power switch
Boot button
Reset button
Antenna connector
L26-T module
Test points
USB Flash Drive
Figure 2: L26-T EVB & Kit Accessories
EVB
GNSS Module Series
L26-T EVB User Guide
USB Cable
Bolts and
Coupling Nuts
