8.4.1

Over the product web-server

NOTICE
security risk due to default passwords.
Unauthorised persons can log in to the web server and change
the product parameters.
▶ Change default passwords.
▶ If the web server is not needed, then disable access with the
Bürkert Communicator software. Refer to chpt. 10.3.2.
prerequisites:
• Digital device (PC, tablet,...) with a web browser.
• Possibly, a USB-Ethernet adapter.
procedure:
1. Connect the product to the digital device with an Ethernet
cable. Alternatively, you can connect the product to the PC
over a USB-Ethernet adapter.
2. Energise the digital device and the product.
3. If you have connected the product to the digital device over
a USB-Ethernet adapter, then configure the IP address of the
USB-Ethernet adapter. Else, configure the IP address of the
network card of the digital device.
→ Change the IP address to 192.168.1.xxx, where xxx is dif-
ferent from 100.
42
English
Type 8745 Ethernet, 8745 Analogue
Electrical installation
4. Open the web browser. In the address bar of the web
browser, enter 192.168.1.100.
The home page of the product web server opens. You can read
some product data.
5. To configure the network parameters of the product, open a
web server session.
→ If you are not automatically invited to log in, choose login.
→ name: enter admin
user
→ User password: enter admin
→ Click login.
6. Change the default passwords with customized passwords.
7. Change the network parameters of the product.
→ Go to industrial communication
→ Change the parameters.
→ To save the changes, choose apply.
→ To update the parameters in the product, choose restart.
The product restarts.
The network parameters of the product are changed.
8.4.2 Over the Bürkert Communicator
software
procedure:
1. Connect the product to the Bürkert Communicator software.
Refer to chpt. 10.4.
2. Change the network parameters of the product.
Configuration
