Mounting The Corebuilder System Into A Distribution Rack - 3Com CoreBuilder 2500 Getting Started Manual

2-4 C 2: I
HAPTER NSTALLING THE
Placement of
CoreBuilder ™
2500 system
(2U)
Figure 2-3 Placement of the CoreBuilder
a Distribution Rack
Be sure that you select holes that are parallel to
each other on the mounting rails.
If the rack does not have threaded holes, insert the
5
"G" clips into the holes you have identified for
mounting and then go to the next section.
If the holes are threaded, you do not need to insert
"G" clips. Proceed to the next section to mount
your system.
S
YSTEM
Hole 1
Hole 6
™
2500 System in
Mounting the CoreBuilder System into a
Distribution Rack
To mount the system into a distribution rack:
Carefully lift the system into place, aligning the
1
mounting brackets with the designated mounting
holes.
Hole
#1
2U
Hole
#6
Figure 2-4 Aligning Mounting Bracket and Rack Holes
While holding the CoreBuilder system in place,
2
insert the four mounting screws (10/32 x
Phillips) into the designated mounting holes on both
sides of the rack. See
™
CoreBuilder 2500
R
Power Run
Green = Active
Yellow = Error
Board
Error
Inserted
Green = Active
Yellow = Error
Board Error
1
/
2
Figure 2-4.
Proc
1
1
