No Symbol Symbol
Name
Light luminance will dim, the
contaminant level indicator will turn off and
the button beep sound will be silenced.
Speed and timer are adjustable in sleep
Sleep
mode. Button luminance return to normal
Mode
upon exiting SLEEP mode. When the purifier
is entering sleep mode, an eight hour timer
will automatically begin. The timer can be
turned off manually.
The purifier operates on maximum speed
Turbo
capacity. Quit by adjusting speed manually or
Mode
switch to another mode.
Power
Press to turn the purifier on or off.
Getting Started
Installing Filter
Before using the appliance, remove all packaging materials covering all of the
filters and place the filters into the appliance as described below.
Please ensure that the correct filter installation sequence is followed.
Otherwise there may be damage to the product, and the filtration and
Note
sterilization effects of the unit may not be as effective as advertised.
Meaning
Step1 As shown in Figure: With both
hands on the upper side of the
machine, first pull the front case in the
1 direction, and then lift the front case
in direction 2.
Activated
carbon
filter
Step 3 Place activated carbon filter
screen as shown in the figure. Grasp
the activated carbon filter in the
direction of the arrow and put the
unpacked activated carbon filter back
into the appliance with the tag pointing
towards you.
PRO-Cell
Catalyst
Step 2 Place the PRO-Cell Catalyst in
the innermost position closest to the
UVC lamp as shown in the figure.
Grasp the photocatalyst filter in the
direction of the arrow and put the
unpacked photocatalyst filter back
into the appliance with the tag
pointing towards you.
HEPA
Filter
Step 4 Place the HEPA filter as shown
in the figure. Grasp the high-efficiency
HEPA filter as shown by the arrow
and put the unpacked high-efficiency
HEPA filter back into the appliance
with the tag pointing towards you.
