Cellink BIO X User Manual page 8

02 Technical specifications
• Compatible with CELLINK thermoplastic cartridge.
• Dimensions (height x width x depth):
• With cartridge (no tubing or nozzle): 165 x 32.5 x 44 mm.
• Without cartridge or nozzle: 129.5 x 32.5 x 44 mm.
• Weight: 260 g.
• Maximum recommended pressure: 700 kPa. We recommend using an external pump with
the Thermoplastic Printhead.
• Material composition:
• External surfaces: Stainless steel.
• Internal surfaces (metal cartridge): Stainless steel.
• Insulators: Polyether ether ketone (PEEK).
• Recommended operating temperature: 20-23 degrees Celsius.
• Running temperature (in recommended conditions): 26-32 degrees.
• Heating capacity and rate:
• Total heating range: 30-250 degrees.
• Heating rate: Room temperature-250 degrees (15 minutes).
• Cooling capacity: N/A.
• Build volume (X, Y, Z): 128 x 85 x (37–A) mm (A = tip length).
4
