04 Getting started
3. Assemble the Thermoplastic Printhead (Figure 3).
A
• Place the plunger inside the metal cartridge. Attach the
top cap. (Plunger use is optional.)
• Insert the assembled cartridge into the Thermoplastic
Printhead (Figure 3A). Twist until the cartridge is screwed
into place. Use the wrench to tighten (Figure 3B).
• Position the insulated locking ring downward to secure
C
B
the assembled cartridge to the Thermoplastic Printhead
(Figure 3C).
Figure 3: Thermoplastic Printhead assembly.
