INSTALLATION and OPERATION MANUAL
Submersible Sewage Ejector
IMPORTANT:
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program, product
changes may occur. As such Crane Pumps & Systems, Inc., reserves the right to change product
without prior written notification.
PUMPS & SYSTEMS
A Crane Co. Company
420 Third Street/P.O. Box 603
Piqua, Ohio 45356-0603
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
Air-Filled
SERIES: 6SE-EHA
10 - 30HP, 1150RPM
SERIES: 6SE-EHA
30 - 100HP, 1750 RPM
DISCONTINUED
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Parts may
NOT be available
Form No. 096963-Rev. B
Advertisement
Table of Contents
Related Manuals for Crane BARNES 6SE-EHA Series
Summary of Contents for Crane BARNES 6SE-EHA Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems, Inc., reserves the right to change product without prior written notification.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNINGS AND SAFETY PRECAUTIONS................3 A. PUMP SPECIFICATIONS.....................4 B. GENERAL INFORMATION....................5 C. INSTALLATION ........................5 - 6 ELECTRICAL DATA ......................7 D. START-UP OPERATION ......................7 E. PREVENTATIVE MAINTENANCE..................9 F. SERVICE and REPAIR ......................9 - 10 TROUBLE SHOOTING ......................11 G. REPLACEMENT PARTS ......................12 CROSS-SECTION, (Fig. -
Page 3: Warnings And Safety Precautions
SAFETY FIRST! PLEASE READ THIS BEFORE INSTALLING OR OPERATING PUMP. GENERAL 1. Most accidents can be avoided by using COMMON SENSE. 2. Read the operation and maintenance instruction manual supplied with the pump. 3. Do not wear loose clothing that may become entangled in the impeller or other moving parts. 4. -
Page 4: Pump Specifications
SECTION: A- PUMP SPECIFICATIONS DISCHARGE: 6" (152mm) 125 lb, Horizontal. UPPER BEARING: LIQUID TEMPERATURE: 104°F (40°C) Continuous. Design: Single Row, Ball VOLUTE: Cast Iron, ASTM A-48 Class 30, Lubrication: Grease With Bronze Wear Ring. Load: Radial MOTOR HOUSING: Cast Iron ASTM A-48, Class 30. LOWER BEARING: SEAL PLATE: Cast Iron ASTM A-48 Class 30. -
Page 5: General Information
Inc. representative or Barnes Pumps, Inc. Service Department Congratulations! You are the owner of one of the finest pumps ® in Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps & on the market today. Barnes Pumps are products engineered Systems Canada, in Brampton, Ontario, and manufactured of high quality components. - Page 6 Make sure the rails are in a true vertical position so the pump C-4.4) Overload Protection: will clear the access opening and will slide freely down the rails The normally closed (N/C) thermal sensor is embedded in the into place on the discharge stationary fitting. Once the rails are motor windings and will detect excessive heat in the event an in proper alignment, bolt the base elbow into the floor of the overload condition occurs.
-
Page 7: Electrical Data
MODEL VOLT NEMA FULL LOCKED CORD CORD CORD WINDING (Nom) CODE LOAD ROTOR SIZE TYPE RESISTANCE AMPS AMPS MAIN 6SE10036EHA 1150 31.0 161.0 SOW-A 0.985 0.39 6SE10046EHA 1150 15.5 80.5 SOW-A 0.985 1.59 6SE15036EHA 1150 39.0 218.0 SOW-A 0.985 0.24 6SE15046EHA 1150 19.5... - Page 8 POWER THREE PHASE, 200- 230 VOLT AC Large Cable Power Cable Motor Lead Number Green (Ground) Green White 2 & 8 3 & 9 Black 1 & 7 4, 5 & 6 Together T1 T7 T2 T8 T3 T9 T4 T5 T6 MOTOR LEADS POWER THREE PHASE, 460 VOLT AC...
-
Page 9: Preventative Maintenance
SECTION E: PREVENTATIVE MAINTENANCE The impeller is keyed onto the shaft with a square key (21-supplied with motor) and to remove, pull impeller straight off the shaft using a wheel puller if required. Inspect gaskets As the motor is Air-filled, no lubrication or other maintenance (10) if suction cover (6) has been removed, and gasket (11) if is required, and generally Barnes Pumps will give very reliable adapter plate (2A or 2B) has been removed, and replace if cut... - Page 10 MOTOR END IMPORTANT ! (INBOARD END) Mounting Plate IT IS EXTREMELY IMPORTANT TO KEEP SEAL FACES (Motor) CLEAN DURING ASSEMBLY. DIRT PARTICLES LODGED BETWEEN THESE FACES WILL CAUSE THE Stationary Seal SEAL TO LEAK. (20A) Assembly (20) Rotating Member (20B) Reliance Motor Seal Pusher Stationary (20A)
-
Page 11: Troubleshooting
TROUBLESHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH "CAUSE"... -
Page 12: Replacement Parts
SECTION: G REPLACEMENT PARTS G-1 ORDERING REPLACEMENT PARTS: When ordering replacement parts, ALWAYS furnish the following information: 1. Pump serial number and date code. (Paragraph G-4) 2. Pump model number. (Paragraph G-3) 3. Pump part number. (Paragraph G-2) 4. Part description. 5. -
Page 13: Cross-Section, (Fig. 6)
320 FRAME 250 FRAME Fig. 6... -
Page 14: Exploded View, (Fig. 7)
Fig. 7... -
Page 15: Parts List
PARTS LIST ITEM DESCRIPTION PART NO. Hex Hd Screw, 250 Frame 5/8-11 x 2.75" Lg, Stainless 1-97-1 Hex Hd Screw, 320 Frame 5/8-11 x 1.75" Lg, Stainless 1-93-1 Adapter Plate, Cast Iron 250 Frame 014-00013-101 Adapter Plate, Cast Iron 320 Frame 014-00014-101 Volute 014-00100-101... - Page 16 NOTE: 1 Standard motor includes, 25 foot power and control cables, moisture & temperature sensors and carbon/ceramic/buna-n Inner & Outer shaft seals. NOTE: 2 When ordering motor (item 17), Outer seal is supplied. Item 20 is for Outer seal replacement ONLY. When ordering outer seal, furnish Reliance motor serial number.
-
Page 17: Returned Goods Policy
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A "RETURNED GOODS AUTHORIZATION". - Page 18 No rights extended under this warranty shall be assigned to any other person, whether by operation of law or otherwise, without our prior written approval. PUMPS & SYSTEMS A Crane Co. Company 420 Third Street/P.O. Box 603 83 West Drive, Brampton...
-
Page 19: Start-Up Report
This report is designed to insure the customer that customer service and a quality product are the number one priority with Crane Pumps & Systems, Inc. (CP&S). Please answer the following questions completely and as accurately as possible. Mail this form to: In U.S.A. - Page 20 CP&S Control Panel Part No. and Brand Number of pumps operated by control panel NOTE: At no time should holes be made in top of control panel, unless proper sealing devices are utilized. Control Panel Manufactured by Others: Company Name: Model No.
-
Page 21: Warranty Registration
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. FOLD HERE ** IMPORTANT ! ** WARRANTY REGISTRATION CUSTOMER’S NAME... - Page 22 FOLD HERE AND TAPE, DO NOT STAPLE PLACE STAMP HERE CRANE PUMPS & SYSTEMS, INC. WARRANTY SERVICE GROUP 420 THIRD STREET P.O. BOX 603 PIQUA, OHIO 45356-0603 - U.S.A.
