Copeland Furniture Canto Instructions

Please
identify the
listed items
before
installation.

Tools required

Step 1:
Install two hair pin legs to
the leg rail
Installing the hair pin legs by placing
the mount plate into the cut-out in the
leg rail (Figure 2). Align the four
mounting holes on the hair pin leg
mount plate and the holes in the cut-out
in the leg rail. Make sure the bottom of
leg is facing out (Figure 1). Use the
provided Allen wrench to tighten the
legs with ¼ - 20 x 25mm Allen bolts.
¼ - 20 x 25mm
hex bolt
Instructions for Canto Beds
Hardware included:
¼ - 20 x 15mm hex bolts (8)
¼ - 20 x 25mm hex bolts (8)
¼ - 20 x 50mm hex bolts (4)
Allen wrench (1)
"L" bracket (2)
Siderail w/ hardware (1)
Canto bed w/ upholstered headboard
62 5/8" x 87 3/8" x 43"
Queen
78 5/8" x 87 3/8" x 43"
King
74 5/8" x 91 3/8" x 43"
Cal King
Allen wrench (provided)
Figure 2.
1 ¾" pan head screw (3)
Platform w/ hardware (1)
Bottom of leg is
facing out
Figure 1.
The install potion of the legs
Hair pin leg w/ mount plate
Install the hair pin leg
Components included:
Upholstered headboard (1)
Footboard rail (1)
Metal hairpin legs (2)
Siderail L (1)
Platform kit (1)
10 3/8" support blocks (3)
Leg rail
Leg rail
Siderail R (1)
Leg rail (1)
1
