Ierīces uzstādīšana
3.2.1 Piekares urbumu urbšana
Piestipriniet uzstādīšanas veidni tvaika nosūcēja
uzstādīšanas vietā. Urbiet punktus, kas marķēti
ar (X,Y) (4. attēls),, izmantojot Ø 8 mm uzgali, un
punktus, kas marķēti ar (Z) (4. attēls), izmantojot
Ø 6 mm uzgali.
X
Ierīces apakšējā virsma
(4. attēls)
Tvaika nosūcējs / Lietošanas instrukcija
Z
Y
GATAVOŠANAS ZONA
8
8 mm plastmasas
8
6 mm plastmasas
sienas tapa
sienas tapa
Z
Z
Y
Y
X
8
X
297 / LV
