3 Installing your appliance

3.1 Installation accessories

1 x flue connection plate
1 x Ø120/150 mm plastic
flue adapter
Information required for the preparation of the in-
stallation place for your hood is given below.
3.2 Installing the hood onto
the wall
To install the hood onto the wall, loosen the
screws of hanger plates on the motor housing and
pull the plates upwards. Then, tighten the screws
of the hanger plates. (Figure 3a).
(Figure 3a)
10 / EN
External flue connection plate
(Figure 3b)
If you will use Ø 120 mm flue pipe, install Ø 120
mm flue adapter onto it.
Hanger plate
