Right Ramp Assembly; Right Ramp Riveted Assembly - Stern Pinball LED ZEPPELIN PRO Service And Operation Manual

PARTS REFERENCE

5.22 RIGHT RAMP ASSEMBLY

511-2957-00
2
1
8
ID Part Number Description
1 510-1025-00 RIVETED ASSEMBLY, RIGHT RAMP, LED
ZEPPELIN
2 520-8116-00 PCB, IR OPTO RECEIVER, ANTI-ROTATION
3 520-8115-00 PCB, IR OPTO EMITTER, ANTI-ROTATION
4 242-5079-00 WASHER, .150 I.D. X .312 O.D. X .050 THICK 2
5 240-5303-00 4-40 NYLON LOCK NUT
6 626-5057-01 RUBBER BUMPER - BLUE
7 535-1355-00 RIGHT RAMP EDGE PROTECTOR PRO
8 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS
9 523-0033-00 FISCHE PAPER, MINI OPTOS
54
ITEM # QTY PART #
1 1 515-2210-00 RIGHT RAMP, RANGER
2 1 535-2276-00 FLAP, RIGHT RAMP, RANGER
3 2 249-5008-00 RIVET - 1/8 X 1/8
5.23 RIGHT RAMP RIVETED
ASSEMBLY
510-1025-00
9
4
3 5
6
7
ITEM # QTY
1 1
2 1
3 1
4 2
5 2
6 1
7 1
8 2
9 2
Qty
1
1
1
2
1
1
2
2
LED ZEPPELIN PRO MANUAL 500-55R5-01
DESCRIPTION
1
3
2
PART # DESCRIPTION
510-1025-00 RIVETED ASSEMBLY, RIGHT RAMP, RANGER
520-8116-00 PCB, IR OPTO RECEIVER, ANTI-ROTATION
520-8115-00 PCB, IR OPTO EMITTER, ANTI-ROTATION
242-5079-00 WASHER, .150 I.D. X .312 O.D. X .050 THICK
240-5303-00 4-40 NYLON LOCK NUT
626-5057-01 RUBBER BUMPER - BLUE
535-1355-00 RIGHT RAMP EDGE PROTECTOR PRO
237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS
523-0033-00 FISCHE PAPER, MINI OPTOS
RAMP ASSEMBLY, RIGHT, RANGER
511-2957-00
ID Part Number Description
1 515-2210-00 RIGHT RAMP, LED ZEPPELIN
2 535-2276-00 FLAP, RIGHT RAMP, LED ZEPPELIN
3 249-5008-00 RIVET - 1/8 X 1/8
Qty
1
1
2
