- Page 1 LSBAR 336 PR-6811 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
- Page 2 Any future technical change in the user manual won’t be with any further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.
-
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature ●... - Page 4 ●Do not mount the projector directly on inflammable surface. ●Do not project the beam straightly on combustible items and the minimum distance between the projector and illuminated items is 10m. ●A projector should be installed with good ventilation. INSTRUCTIONS ●CLEANING AND MAINTENANCE For the units with optical lens, because of the accumulation of the smoke, oil and dust on lens, the light output will be compromised.
- Page 5 3. APPEARANCE 灯体 Body 螺栓 Bolt Support 支架 4. INSTALLATION ●FIXING FIXTURE (FOR REFERENCE) Place a fixture in the place to be illuminated and use screws to tighten it. Please be sure it is tightened. ●ADJUSTING A FIXTURE’S ANGLE: Use inner hexagon spanner to loosen the adjusting bolt appropriately and rotate the fixture to the angle desired. Based on actual operations, the angle can be between 0 and 150 degrees.
-
Page 6: Dmx Protocol
● TRANSPORTATION Before transportation, tighten screws after the fixture and the support are overlapped. ● POWER CONNECTION Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. -
Page 7: Technical Data
1-128 Forward rotation from slow to fast 129-255 Reverse rotation from slow to fast Green(custom) 0-255 Linear adjusting（0-100%） Blue(custom) 0-255 Linear adjusting（0-100%） Amber(custom) 0-255 Linear adjusting（0-100%） 0-255 Saturation 0-255 Brightness 0-255 Linear adjusting（0-100%） Colour Temperature 1-255 CT from warm to cold（2000K-5700K） Linear dimmer （0-100%）... -
Page 8: Net Weight
Over temperature protection HOUSING High tensile cast Aluminum alloy+ extruding aluminum , IP66 NET WEIGHT 6.2Kg Gross weight 7.2Kg OPERATION TEMPERATURE: 40 ℃ Maximum ambient temperature SIZES: 999*90*145（with the support） The installation diagram of the support 8/12... -
Page 9: Circuit Diagram
7. CIRCUIT DIAGRAM AND FIXTURE CONNECTIONS ● CIRCUIT DIAGRAM 9/12... - Page 10 ● DMX CONTROL SIGNAL CONNECTION AND SIGNAL AMPLIFIER CONNECTION Control signal connection (Please take note of the wiring direction) 接控制器 DMX CONTROLLER 第1台 The 1 fixture DMX OUT DMX IN 第2台 第N-1台 the 2 fixture the N-1 fixture DMX OUT 第N台...
-
Page 11: Component Order Codes
Remarks: 1. Based on the actual operation, select proper quantity of the fixtures; Signal amplifiers like the fixture and other stage products are loads, therefore the total loads are not more than 32pcs in number counting from DMX out interface of the DMX console. - Page 12 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 6320000114...
