Thank you for purchasing this Bosco bed. Please ensure instructions are read in full before attempting to
assemble this product.

Pre-assembly preparation

This is a two person operation
This product is heavy, it should be assembled as near as possible to the point of use. Take care when lifting to
avoid personal injury and (or) damage to the product.
Installation should be carried out exactly according to the manufacturers instructions, otherwise a safety
risk can occur if incorrectly installed. Cabinets and shelving over 600mm high can be unstable and should be
Ref: 1213 / 1360 & 1361 Bosco double / kingsize bed
1360 & 1361 BOSCO
DOUBLE/KINGSIZE BED
Items you will need
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BOSCO 1360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ercol BOSCO 1360

  • Page 1 1360 & 1361 BOSCO DOUBLE/KINGSIZE BED Thank you for purchasing this Bosco bed. Please ensure instructions are read in full before attempting to assemble this product. Pre-assembly preparation Items you will need This is a two person operation This product is heavy, it should be assembled as near as possible to the point of use. Take care when lifting to avoid personal injury and (or) damage to the product.
  • Page 2 Fittings and parts checklist 8 x threads 1 x headboard 8 x half moon washer 1 x footboard 1 x spanner 2 x side rails 2 x central brackets 1 x centre rail 2 x washers 32 x slats double bed 2 x nuts and bolts 34 x slats king size 64 x ends for slats (double)
  • Page 3 Step by step assembly instructions 1. Push the threads (G) into the headboard and the footboard as shown below. Tighten the threads by hand ensuring that there is approximately half of the thread still showing. Using the 12 x 25mm screws (M), attach the two brackets (J) onto the headboard and the footboard using the pre-drilled holes, tighten with a phillips screwdriver.
  • Page 4 3. Push the plastic cap (F) onto the end of each slat (E). With the peg facing downwards push the slat into the pre-drilled holes as shown below. Repeat for each of the slats. The bed is then fully assembled. Slats double bed x 32 Slats king size x 34 Ends for slats double bed x 64...
  • Page 5 No liability will be accepted for damage or injury caused by incorrectly installed furniture. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX ercol.com April 2018 Issue 1 Ref: 1213 / 1360 & 1361 Bosco double / kingsize bed...
