11) Mount the ice maker onto the two ice maker
mounting screws you installed in step 9. Make
sure that the water inlet tube is sitting inside the
fill cup, then tighten the screws.
12) Adjust the leveling bracket to level the ice maker.
The ice maker is level when the gap between the
freezer wall and the ice maker is the same at the
top and bottom.
13) Reinstall the freezer shelf and set the ice storage
bin on the shelf.
14) Locate the pre-punched holes at the bottom right
corner of the back panel of the refrigerator. Align
the bracket of the water valve with the factory
drilled holes, then use a Phillips head screwdriver
to drive the two self-drilling screws through the
bracket and into the cabinet.
