Midea SO-BCD595WM-UT Service Manual page 12

Service Manual, 2016-12
7、Remove the hole cap from the top left of the
refrigerator door and insert it in the other side.
8、Remove the door block from the bottom right
side of the freezer and refrigerator door and attach it
to the other side.
9、 Remove the two hole caps from the left side,
where the center hinge will go,and insert them into
the other side.
10、 Attach the refrigerator door on the bottom
hinge, then attach the center left hinge to the left
side of the refrigerator.
11、Put the freezer door onto the center left hinge,
then attach the top left hinge to
the top of refrigerator. Cover the hinge with the top
left hinge cover and cover the screw
holes on the right side of the top with the cover plate
you previously removed.
12 / 45
