Service Manual_2020-V1.0
Service Manual
SBS Series
Applicable Models
Product Models
Applicable Models
HC-689WEN
CE-BCD530WE-SQ
22031050000921
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer
to accumulate through the daily work.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea CE-BCD530WE-SQ
Summary of Contents for Midea CE-BCD530WE-SQ
- Page 1 Applicable Models Product Models Applicable Models HC-689WEN CE-BCD530WE-SQ 22031050000921 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer...
- Page 2 Service Manual_2020-V1.0 WARNING Important Safety Notice There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.
- Page 3 Service Manual_2020-V1.0 1. Significant update notes (None)
- Page 4 Service Manual_2020-V1.0 2. Safety Warning 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer.
- Page 5 Service Manual_2020-V1.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
- Page 6 Service Manual_2020-V1.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance.
- Page 7 Service Manual_2020-V1.0 3. Installation and commissioning 3.1 Handling Handling Protect the refrigerator in moving it,Same as shown as left photo, please move it by handcart with cushion Remove all packing materials and bottom cushion, the move into house for placement After moving it to appropriate location, wait for 2 hou rs before power on.
- Page 8 Service Manual_2020-V1.0 2) Disconnect the connectors, then use cross screwdriver or socket spanner to remove the 2pcs M5 screws and 1 pc grounding screw by anticlockwise, then remove the upper hinge. 3) Lift up the freezer door until the hinge axis and water pipe separated from the axis hole of door, then carry the door to a suitable place.
- Page 9 Service Manual_2020-V1.0 3) Lift up the refrigerator door until the hinge axis separated from the axis hole of door, then carry the door to a suitable place. Assembly of freezer door 1) Put the freezer door down gently until the axis of hinge inserted into the axis hole of door completely.
- Page 10 Service Manual_2020-V1.0 3) Put the cover of upper hinge on suitable position, then use screwdriver to fix the 2 pcs screws assembly of refrigerator door 1) Put the refrigerator door down gently until the axis of hinge inserted into the axis hole of door completely, and then closes the door, to make sure the refrigerator door fit the cabinet closely.
- Page 11 Service Manual_2020-V1.0 3.3 Installation location Installation location Please select a ventilated place to place the refrigerator, and reserve space according to the recommended size in the picture, which is conducive to heat dissipation, performance improvement and energy consumption reduction. 3.4 Leveling of the refrigerator Leveling of the refrigerator If the refrigerator cannot be placed steadily, adjust the footing to level it.
- Page 12 Service Manual_2020-V1.0 3.6 Installation of handle（Option） Installation of handle 1) Take out 4 bolts from the plastic bag containing the user manual, and fix the bolts in the screw holes on the door with a cross screwdriver. 2) Install the door handle onto the bolt, tighten the screw in the handle side hole with the Allen wrench in the plastic bag, install the screw cover, and complete the installation.
- Page 13 Service Manual_2020-V1.0 Adjustment to inhomogenous aperture the door (Up and down) 1) Use screwdriver to remove the 2 pcs screws, and then remove the upper hinge cover. 2) Use screwdriver to loosen the 2 pcs screws, right and left adjust the upper hinge to make door aperture be homogeneity.
- Page 14 Service Manual_2020-V1.0 4. Main parts and external dimension 4.1 Main parts (The picture is only for reference, and specific appearance and configuration are subject to the real product)
- Page 15 Service Manual_2020-V1.0 7. Dismantling of parts 7.1 Parts on the door Door seal Door seal is installed into door liner groove. 1)Open the refrigerator door; 2)Take the door seal ① out of door liner; Door tray While squeezing it inward, lift up the door tray and take it out from door liner.
