Summary of Contents for NXP Semiconductors TWR-KM35Z75M
- Page 1 Quick Start Guide TWR-KM35Z75M Tower System for KM35Zx Family of MCUs Power-Efficient, 75 MHz Arm Cortex -M0+ Based MCUs ® ® TOWER SYSTEM DEVELOPMENT PLATFORM...
- Page 2 DS1 Segment OpenSDA Micro USB J26 K20 JTAG J25 GPIO Header Header SW4 Reset Button D2 Yellow LED MKM35Z512VLQ7 J24 KM35 SWD J23 TWRPI J31 PWM Header D3/D4/D5 LEDs J22 TWRPI IRDA Accelerometer MMA8451Q Figure 1: Front side of TWR-KM35Z75M board...
- Page 3 TWR-KM35Z75M Tower System Development Platform The TWR-KM35Z75M board is designed to work either in standalone mode or as part of the NXP Tower System, a modular development board platform that enables rapid prototyping and tool re-use through reconfigurable hardware. Begin constructing your Tower System evaluation board platform today by visiting www.nxp.com/Tower for...
- Page 4 Quick Start Guide FEATURES • Tower-compatible microcontroller • Headers for direct GPIO and ADC module access • KM35Z512VLQ7 MCU (75 MHz, 512 KB • External tamper pins Flash, 64 KB RAM, low power, LQFP144 • Independent, battery-operated power package) supply for real-time clock (RTC) and •...
-
Page 5: Install Software
STEP-BY-STEP INSTRUCTIONS In this Quick Start Guide, you will learn how to set up the TWR-KM35Z75M board and run the included demonstrated software. For more detailed information, review the user manual at nxp.com/TWR-KM35Z75M. Confirm Segment Download Software The Segment LCD displays as below: Download installation software •... - Page 6 Quick Start Guide EXPANDED SOFTWARE AND TOOLS Additional details regarding the Quick Start Demo are included as part of the MCUXpresso software development kit (SDK). To take your design to the next level, leverage the MCUXpresso SDK and other online enablement software and tools for NXP MCUs available at nxp.com/MCUXpresso.
- Page 7 TWR-KM35Z75M JUMPER OPTIONS The following is a list of all the jumper options. The default installed jumper settings are indicated in the shaded boxes. JUMPER OPTION SETTING DESCRIPTION Connect VBAT to on-board 3.3 V supply MCU power Connect VBAT to the higher voltage between...
- Page 8 Quick Start Guide TWR-KM35Z75M JUMPER OPTIONS CONTINUED JUMPER OPTION SETTING DESCRIPTION Connect MCU IRDA transmit signal IRDA transmit Disconnect MCU IRDA transmit signal Connect MCU IRDA receive signal IRDA receive Disconnect MCU IRDA receive signal MCU powered from V_BRD 3.3V on board reg.
- Page 9 TWR-KM35Z75M JUMPER OPTIONS CONTINUED JUMPER OPTION SETTING DESCRIPTION OpenSDA KM35 reset input driven by K20 OpenSDA reset KM35 reset input isolated from OpenSDA enabled Connect MCU EXTAL pin to crystal 8M Crystal Connect MCU EXTAL pin to external clock...
- Page 10 Quick Start Guide GPIO HEADER (J25) SIGNAL CONNECTIONS MCU SIGNAL J25 PIN MCU SIGNAL SW3 (Tamper swich) SW3 to TAMPER0 (when closed) SW3 (Tamper swich) SW3 to TAMPER0 (when closed) SW3 (Tamper swich) SW3 to TAMPER0 (when closed) V_BRD PTK5/UART1_RX PTK6/UART1_TX PTL0/I2C0_SDA PTK7/I2C0_SCL...
- Page 11 www.nxp.com ANALOG INPUTS/GENERATOR OUTPUTS (J31) MCU SIGNAL J31 PIN MCU SIGNAL EXT_PWM0 EXT_SD_ADP0 VSSA_AFE EXT_SD_ADM0 EXT_PWM1 EXT_SD_ADP1 VSSA_AFE EXT_SD_ADM1 EXT_PWM2 EXT_SD_ADP2 VSSA_AFE EXT_SD_ADM2 EXT_PWM3 EXT_SD_ADP3 VSSA_AFE EXT_SD_ADM3 EXT_PWM4 EXT_SAR_AD0 EXT_PWM5 EXT_SAR_AD1 EXT_PWM6 EXT_SAR_AD2...
-
Page 12: Warranty
WARRANTY under “Jump Start Your Design” at Visit www.nxp.com/warranty for www.nxp.com/TWR-KM35Z75M. complete warranty information. www.nxp.com NXP, the NXP logo and Kinetis are trademarks of NXP B.V. All other product or service names are the property of their respective owners. © 2020 NXP B.V.
