Summary of Contents for NXP Semiconductors Freescale Kinetis TWR-KV58F220M
- Page 1 TWR-KV58F220M Quick Start Guide Tower System Development Platform for Motor Control...
- Page 2 Quick Start Guide Get to Know the TWR-KV58F220M Board LEDs LED Jumpers Cortex M Programming General Purpose Header TWRE Connectors Potentiometer User Pushbuttons Open SDA USB Connector UART Selection Reset Button KV58F1M0VLQ22 Jumpers Figure 1: Front side of TWR-KV58F220M...
- Page 3 freescale.com TWR-KV58F220M Tower System Development Board The TWR-KV58F220M Tower System Board is a standalone development kit that can be used in conjunction with the Tower System development platform and the TWR-MC-LV3PH motor control module. To watch a video on how to configure the board, go to freescale.com/TWR-KV58F220M. This Quick Start Guide will teach you: •...
-
Page 4: Software Installation Instructions
Quick Start Guide TWR-KV58F220M Software Installation Features Instructions • MKV58F1M0VLQ22 MCU (ARM ® Download Software Cortex -M7 220 MHz, 1 MB flash, ® and Tools four 12-bit ADCs up to 5 Msps, 4x FlexTimers and 2x eFlexPWM with Download installation 284ps resolution, up to 44x PWM software and documentation channels, 144 LQFP) -
Page 5: Initial Configuration
freescale.com TWR-KV58F220M Initial Configuration Default Jumper Settings Atollic TrueStudio at http://www. atollic.com/index.php/truestudio. See the default jumper settings ARM GCC at launchpad.net/gcc-arm- in the table below. Refer to the TWR- embedded. KV58F220M User Guide at freescale.com/ • Install the mbed serial drivers TWR-KV58F220M for detailed jumper located at http://developer.mbed. - Page 6 Quick Start Guide TWR-KV58F220M Initial TWR-KV58F220M Tower Configuration (cont.) System Module Demo Verification of Program a Precompiled Jumper Setting Example Using the OpenSDA MSD Application TWR-KV58F220M comes preloaded with the CMSIS-DAP applications (MSD flash 1) Connect your TWR-KV58F220M to your programmer and debug) and the bubble_ host PC.
- Page 7 freescale.com TWR-KV58F220M Tower System Module Demo (cont.) 2) Program a precompiled example for the Kinetis KV5x MCU in the MBED drive, Debug Your copy any binary file from the precompiled examples folder of the Quick Start First IAR Project Package. The demo will start automatically 1) Open the Kinetis SDK Getting Started when the download is complete.
- Page 8 Quick Start Guide Running a 3-Phase PMSM Motor TWR-KV58F220M and TWR-MC-LV3PH Set Up 1) Connect the boards and the motor. TWR-MC-LV3PH: Jumper Settings Connect TWR-KV58F220M and TWR-MC- LV3PH with the default jumper settings for Option Setting Option Setting the Kinetis KV58F220M and the jumper setup shown in the table for the TWR-MC- 1–2 LV3PH.
- Page 9 freescale.com Monitor the Project with Open the FreeMASTER project file pmsm_ demo_twr-kv58.pmp following the path FreeMASTER <TWR-KV58F220M Quick Start Pack root Launch Freescale FreeMASTER 2.0 from directory>/Freemaster/PMSM_ Sensorless_ the Windows Start menu. FOC. The application interface, PMSM Sensorless Vector Control on Kinetis, Note: At first start-up, you may have will appear in FreeMASTER.
- Page 10 Quick Start Guide Running a 3-Phase PMSM Motor (cont.) In the Project Options, set the COM port affected to the OpenSDA -CDC Serial Port (info available in Device Manager) and set the baud rate/speed to 19200 bps (check the option “Do not Open Port at Startup” to avoid error messages at FreeMASTER startup).
- Page 11 freescale.com...
-
Page 12: Get Started
Get Started Download installation software and documentation under “Jump Start Your Design” at freescale.com/TWR-KV58F220M. Support Visit freescale.com/support for a list of phone numbers within your region. Warranty Visit freescale.com/warranty for complete warranty information. For more information, visit freescale.com/TWR- KV58F220M, freescale.com/Kinetis freescale.com/Tower Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg.
