SunSetter EasyShade Replacement page 3

19. Ensure the Vinyl Coated Cables are snug. Adjust as needed, using the 7/16" open end wrench, by turning the
nut on the Cable Guide Stop until the Cable is snug.
Note: Do not overtighten the Cable.
20. Plug the power cord into the electrical outlet.
21. Test the operation of your EasyShade, using the DOWN and UP buttons on your Remote Transmitter.
22. If you need to adjust the Down or Up Stop Limits, follow these steps:
Note: Do Not exceed the 84" Open Limit as this will cause the screen to roll up backwards in the housing.
To Change the Up Limit:
Move the EasyShade to its current Up limit position
and let it stop. Press the (UP)
buttons simultaneously (see Figure 11) until the
EasyShade jogs, then release. Adjust to a new Open
limit position. Press the (MY)
EasyShade jogs, then release. Check the new Up limit.
Figure 11
and (DOWN)
button until the
To Change the Down Limit:
Move the EasyShade to its current Down limit position
and let it stop. Press the (UP)
buttons simultaneously (see Figure 10) until the
EasyShade jogs, then release. Adjust to a new Down
limit position. Press the (MY)
EasyShade jogs, then release. Check the new Down
limit.
3
and (DOWN)
button until the
