Bell System Practices Plant Series Adjustments page 92

573-115-700
SECTION
3.15
Selective Calling Mechanism (Cont.)
LIN E FEED ( Stunt Case
CONDITION CODE SHIFT FORK SPRING
REQUIREMENT
WITH CONDITION CODE SHIFT IN ITS UNO PERATED POSITION.
1
MIN. OZ.
MAX. 3
OZS.
TO PULL SPRING TO ITS INSTALLED POSITION.
LOWER GUIDE PLATE
(T O P VI E W)
92
P a ge
) FUNCTION BAR
rn
AUTOMA TIC CARRIA GE RETURN -LINE FEED BLOCK ING SLIDE SPRING
REQUI REMEN T
WITH COND ITION CODE SHIFT FORK IN ITS UNOPE RATED POSITI ON.
MIN.
MAX. 3
TO PULL SPRING TO ITS INSTALLED PO SITION
AUTOM ATIC CA RRIAG E RETUR N FUNCT ION BA
1
OZ.
OZS.
(F RONT VI E W)
BLOCKING SLIDE SPRING
-
