2.04
Selector Mechanism (Cont.)
SELECTOR ARMATURE SP RING
REFE R TO PAR.
2.05
USING THE FOLLOWING:
(500
MA SELECTOR COILS
SINGLE BUTTON ARMATURE
500
MA; MIN
DOUBLE BUTTON ARMATURE
500
MA; APPROXIMATELY---
TO PULL REAR BUTTON AGAINST ITS POLE PIECE
ISS 7, SECTION 573-115-700
OZS ---MAX
5-1/2
OZS
1-l/8
OZ
Page 11
