Bell System Practices Plant Series Adjustments page 86

SECTION 573-115-700
Horizontal Tabulator Mechanism (Cont.)
3.09
RIGHT MARGIN
TABULATOR STOP
TABULA TOR SiOP SETTIN GS
N OTE:
FOR INSTRU CTION S ON HOW TO MOVE TABULA TOR STOPS, SEE TABULA TOR
ADJUS TM ENT. PAR. 3.06
COLUMNAR TABULATOR STOPS
(l)
PLACE CARRIAG E IN POSITION TO PRINT FIRST CHARACT ER IN COLUMN .
IMMEDIA TELY TO i.EFT OF PAWL.
ROTATE DRUM TO MORE ACCESSI BLE POSITIO N.
NUMBER OF SPACING OPERATI ONS FROM LEFT MARGIN AND PLACE STOP CORRESP O
NUMBER OF SLOTS COUNTE RCLOCKW ISE FROM ROLLER.
NOTE: WHEN PRINTING FORMS, CHECK STOP SETTINGS IN RELATION TO COLUMNS .
CORRESPONDING STOPS ON ALL MACHINES ON
OF SLOTS FROM LEFT MARGIN.
(2) RIGHT MARGIN TABULATOR STOP (WITH WIDE SHELF)
BEFORE MAKING THIS ADJUSTMENT,
NOTE:
ADJUSTMENTS.
POSITION PRINTING CARRIAGE AT RIGHT MARGIN (SPACING CUTOUT OPERATED).
WITH WIDE SHELF IN SLOT IMMEDIATELY TO LEFT OF PAWL.
SO THAT PAWL RESTS ON IT.
Page 86
TABULA TOR PAWL
(2)
TO FACILITA TE INSERTIN G STOPS, MARK DESIRED SLOT AND
COLUM NAR TABULA TOR STOP
FRONT VIEW
FOR SETTING S NEAR LEFT MARGIN
CIRCUIT MUST BE THE SAME NUMBER
A
CHECK RIGHT MARGIN AND TABULATOR PAWL
ShELF SHOUL D EXTEN D TO RIGHT
PAWL PRELIM INARY
PLACE STOP IN SLOT
COUNT
N
DING
INSERT STOP
