Predelivery inspection
Hide thumbs Also See for DS 250:
Table of Contents

Advertisement

Quick Links

June 4, 2010
YEAR
2011

TABLE OF CONTENTS

IMPORTANT NOTICE ........................ 2
UNCRATING ................................... 3
PARTS TO BE INSTALLED.................. 4
Battery ............................................ 4
Wheels ............................................ 4
Mirrors ............................................ 5
Vehicle Decals.................................... 5
Accessories Installation......................... 5
Handlebar ......................................... 5
FLUIDS.......................................... 7
Fuel ................................................ 7
Engine Oil......................................... 7
Gearbox Oil ....................................... 8
Engine Coolant................................... 9
Brake Fluid....................................... 10
SET-UP......................................... 11
Tire Pressure .................................... 11
Brake Discs Cleanup ........................... 11
Protective Materials ............................ 11
ADJUSTMENTS ............................. 11
General Guidelines ............................. 11
Carburetor ....................................... 11
Drive Chain ...................................... 11
Transmission Lever............................. 12
Suspension ...................................... 12
Brake ............................................. 12
ASSEMBLY INSPECTION .................. 13
FINAL INSPECTION ......................... 13
Vehicle Test Run ................................ 13
Printed in Canada. (vbl2011-003 en DM)
©2010 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.
®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.
Subject: Can-Am™ DS 250™ Predelivery Inspection
MODEL
DS 250
Page
MODEL NUMBER
3JBA / 3JBB / 3JBC
Vehicle Cleaning ................................ 13
Delivery to Customer .......................... 13
TECHNICAL DATA ........................... 14
2011-2
No.
SERIAL NUMBER
All
Page
1 / 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS 250 and is the answer not in the manual?

Questions and answers

Billy
March 19, 2025

2021 can **** 250 D’Souza service manual

0

Subscribe to Our Youtube Channel

Related Manuals for Can-Am DS 250

Summary of Contents for Can-Am DS 250

  • Page 1: Table Of Contents

    2011-2 June 4, 2010 Subject: Can-Am™ DS 250™ Predelivery Inspection YEAR MODEL MODEL NUMBER SERIAL NUMBER 2011 DS 250 3JBA / 3JBB / 3JBC TABLE OF CONTENTS Page Page IMPORTANT NOTICE ......2 Vehicle Cleaning ........ 13 Delivery to Customer ......13 UNCRATING ........
