No. Part name
480 Strainer Element
481 Retainer, Strainer Element
485 Check Valve Spring
486 Hexagon Nut
487 Plain Washer
488 Seat Stopper
489 Valve Seat
490 Valve Plate
491 Check Valve Shaft
495 O-ring
533 Solenoid Valve
534 Nipple (High Pressure)
535 Connection (L-type)
536 Connection (L-type)
538 Piping
550 Check Union
551 Connection (I-type)
552 Piping
553 Connection (I-type)
554 Angle Valve
555 Angle Valve
556 Connection (I-type)
557 Piping
558 Hexagon Bushing
559 Hose Nipple
 The part code of the O-ring is the one assigned to NBR-70-1 which is standard
material. When the material of the O-ring is other than NBR, a different part code is
used for each material.
If you are using O-rings made from other than the standard material, please
contact MAYEKAWA when placing an order.
