Teldat S.A.
A.1.4 LAN Switch Connector
Devices equipped with this interface have four RJ45 connectors installed.
RJ45 LAN
A.1.5 WWAN/RF Connectors
Devices equipped with this interface have two SMA female connectors installed.
SMA Female
A.1.6 Configuration Connector
RJ45 CONFIGURATION
Regesta Smart PRO
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
PIN
1
2
3
4
5
6
7
8
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
ANT
RF in/out
GND
CONF
--
RxD
GND
--
--
GND
TxD
--
Technical Information
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
35
