Teldat S.A.
Cellular interface
L
corresponding to
the active SIM.
Ethernet LAN inter-
LAN
face
Ethernet WAN in-
WAN
terface (RJ45)
Ethernet WAN in-
SFP
terface (SFP)
Multi standard seri-
S1
al interface 1
Multi standard seri-
S2
al interface 2
Note some LEDs may behave differently depending on how the device is configured.
2.4.2 Connector Panel
The connector panel is covered by a protective casing. To access the former, you need to remove the latter. For fur-
ther information on how to remove/install the protective casing, please see
tector
on page 14.
The following figure shows the panel, which includes all Regesta Smart PRO router connectors.
Regesta Smart PRO
The device has registered in the network and is establishing
Amber
the PDP connection.
The device is registered, PDP connection is established and
Green
IP traffic can be sent through the CELLULAR interface.
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
Cellular interface is not active.
Red
Coverage level below -100dBm.
Amber
Coverage level between -90dBm and -100dBm.
Green
Coverage level above -90dBm.
Off
Ethernet LAN is disabled or connection is not established.
Ethernet connection (link) established:
Green
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
Ethernet WAN is disabled or connection is not established.
Ethernet connection (link) established:
Green
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
SFP is not used.
Green
Ethernet SFP connection (link) is established
Off
Serial port 1 is disabled or not initialized.
Green
Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
Serial port 2 is disabled or not initialized.
Green
Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Removing/Installing the Connectors Pro-
2 Product Overview
9
