3 Installing the Router
To put the protector on, follow the steps below.
First, slide the case down and insert it in its proper position.
To block the case, move the fastening mechanism to a horizontal position and push down. You should hear a little
click.
Warning
The connector's protection case needs to be installed before the device is powered.

3.3 Installing a DIN rail mount accessory

The Regesta Smart PRO can be installed on a standard DIN rail. To mount it on a DIN rail, a special kit is needed.
This kit is included in the delivery. The DIN rail kit allows the device to be installed in different positions.
The kit contains 2 screws to adjust the rail mount to the underside of the device. There are a set of perforations on
the underside that allow you to place the DIN rail mount in two different positions:
