Preparing the rack
5
Rack side view
N5470A Rack Mount Kit
To prepare the rack for sheet metal nut installation, seven rack mount units
must be designated for use. The following diagram shows how to determine a
rack unit.
Rack units may be
designated by arrows.
If not, narrow hole spacing
indicates start/stop point
of rack unit.
This distance is
equivalent to
1 rack unit
Rack front view
