1 Introduction
1.2 The Amersham ImageQuant 800 instrument
Light source
IRshort Epi
IRlong Epi
White Epi
White Trans
A fully equipped filter turret in the Amersham ImageQuant 800 instrument contains the
following emission filters:
Emission filter
Cy2
Cy3(UV)
Cy5
IRshort
IRlong
Note:
The figure below illustrates how these LED light sources and emission filters cover different
wavelength ranges of the light spectrum.
8
Emission wavelength
660 nm
775 nm
470 to 635 nm
470 to 635 nm
Data
525BP20
605BP40
705BP40
715BP30
836BP46
The Amersham ImageQuant 800 instrument can be further equipped with
custom emission filters, see Amersham ImageQuant 800 Operating Instructions.
