Configuring MF1 for Closed Field | 55
Configuring MF1 for Closed Field
MF1 Closed Field Speaker Assembly Diagram
Important
Closed Field Adapter, Tip, and CF Line Filter used only for Closed Field Configuration!
To configure the MF1 for closed field operation:
1.
Ensure Black O-ring is in place on back of CF Adapter, as shown.
Front of Speaker
Back of CF Adapter
