For more information on the RZ6 and full system specs, see the
PC and Interface
The RZ6 must be directly connected to a PC, which provides the user interface for the system.
The PO5 or PO5e optical interface card is installed in the PC and connected to the RZ6 across
fiber optic cables. This adds another layer of noise reduction, separating the processor from
the noisy PC environment.
The PC handles:
• Configuring the hardware and software.
• Communicating with the TDT hardware and transferring data across a fiber optic
interface.
• Displaying and working with data during and after acquisition.
If you use TDT's WS4 computer, the optical interface and BioSigRZ software are pre-installed.
If you use your own PC, you'll need to install the interface card and BioSigRZ software yourself.
Step-by-step instructions for installing software and drivers and setting up the processor are
available in System 3 Installation Guide
includes information for connecting the WS4 or your PC to the RZ6 Processor, including
running a transfer test to ensure communication between them is working correctly.
Note
A UZ3 (USB 3.0) interface is also available if you wish to use a laptop.
that came with your system. The installation guide also
The Test Equipment | 20
System 3 Manual.
