3.1 SPECIFICATIONS

Waterway Size
Max Pressure
Min Pressure
Temperature Rating*
Opening/Closing Speed
Environmental Rating
Motor Opening/Closing Speed
Voltage - Auto Sense
Motor Current - Nominal
Motor Current - Limit
Recommended Fuse Size
*For temperatures below 32°F(0°C), valves must be drained after use to avoid damage.
See section 2.0 SAFETY.
©Copyright Task Force Tips LLC 2014-2019
Electric Motor
AXD1ST-NX-RC
Jumbo Low Profi le Ball Intake Valve RC
With Pressure Relief Valve
General Information
MODEL
Figure 3.0
LOW PROFILE JUMBO INTAKE VALVE
5.25" (133mm)
250 psi (17 bar)
Full Vacuum
-25°F to 135°F (-32°C to 57°C)
Meets NFPA 1965 Slow Close Requirements
All components designed to meet
minimum rating of NEMA 4 (IP65)
6 sec
12 Volt
3 amp
12 amp
15 amp
5
Manual Override
Handwheel
24 Volt
1.5 amp
6 amp
7.5 amp
LIA-208 August 12, 2019 Rev04
