Task Force Tips Ball Intake Valve AXD1ST-NX-T Instructions For Installation, Safe Operation And Maintenance page 11

4.8"
[122mm]
9.4"
[240mm]
AXE1ST-NX-RC
Angled Position
©Copyright Task Force Tips LLC 2014-2019
6.8"
[172mm]
8.8"
[223mm]
12.2"
[309mm]
10.5"
[267mm]
5.6"
[142mm]
Jumbo Low Profi le Ball Intake Valve RC With Pressure Relief Valve
4.8"
[122mm]
8.7"
[221mm]
Figure 3.1.3b
Overall Dimensions:
11
11.3"
[286mm]
10.5"
[267mm]
AXE1ST-NX-RC
Down Position
LIA-208 August 12, 2019 Rev04
6.8"
[172mm]
8.8"
[223mm]
5.6"
[142mm]
