3-2 C 3: T
HAPTER ROUBLESHOOTING AND
R M
EPLACING THE ODULE
WARNING: The use of optical instruments may cause eye hazard.
ATTENTION: L'utilisation d'instruments optiques peut être dangereuse pour
les yeux.
ACHTUNG: Die Verwendung von optischen Instrumenten kann eine Gefahr für
die Augen bergen.
ADVERTENCIA: El uso de instrumentos ópticos puede ser peligroso para
los ojos.
2 Use the screwdriver to unscrew the two captive screws that anchor the module
in the slot until they disengage from the chassis. Do not remove the screws
from the front panel.
3 Push the tab outward from the FDDILink module.
The module disengages from the NETBuilder II backplane and partially ejects
from the slot.
4 Use both hands to grasp the module and gently pull it from the slot.
Install the new module using the procedure in Chapter 1.
