Typical Network
Configuration

Module Components

LEDs

FDDIL M
INK ODULE
Figure 2-1 shows a typical use of a mixed-mode FDDILink module and the
NETBuilder II bridge/router in a network.
FDDILink
Single-mode Multimode
A transceiver B transceiver
NETBuilder II
bridge/router
in building 100
Figure 2-1 Typical Mixed-mode FDDILink Module and NETBuilder II Bridge/Router
Network
This section describes the components of the FDDILink module (see Figure 2-2).
J3
J2
J1
Figure 2-2 FDDILink Module Components
The FDDILink module has three LEDs: One indicates the status of the whole
FDDILink module and the other two indicate the status of the physical fiber
connection to each transceiver. The A STATUS LED corresponds to the left
transceiver, and the B STATUS LED corresponds to the right transceiver. Table 2-2
explains the LED states.
d
SANTA CLARA
FDDILink
campus
Multimode
A transceiver
®
FDDI SC
connectors
Single-mode
B transceiver
NETBuilder II
bridge/router
in building 200
A S S
B Y P
A T U S
B S T
S
A T U
A S T
T U S
S T A
Optical
bypass
Status LEDs
connector
