Module Features

O
VERVIEW OF THE
M
ODULE
This chapter describes the features, specifications, and typical use of the FDDILink
module for the NETBuilder II bridge/router.
Table 2-1 summarizes the features of the FDDILink module.
Table 2-1 FDDILink Module Features
Feature Summary
Hot-swap capability Allows you to install, or remove and reinstall, the module without
turning of the NETBuilder II bridge/router.
Compatibility
Multimode Connects to any FDDILink network through SC connectors. Transceiver
accepts 100 µm 62.5 center core, multimode fiber with 62.5 µm core
and 125 µm cladding.
Single-mode Connects to any FDDILink network through SC connectors. Transceiver
accepts 100 µm 8.7 center core, single-mode fiber with 8.7 µm core
and 125 µm cladding.
Connections Single- or dual-attached capabilities.
Keying Supports and accepts A, B, or S type ports for network connection.
Cable support
Accepts multimode duplex fiber of 62.5/125 µm. An 11-db optical
Multimode
budget size allows cables up to 2 km long.
Accepts single-mode duplex fiber of 8.7/125 µm. An 11-db optical
Single-mode
budget size allows cables up to 15km long.
Flexible topology Topology and capacity can be configured by setting conditions on the
network external to the NETBuilder II base system. The capacity and
topology of the FDDILink network is not fixed. Capacity is determined
by a combination of cable lengths and connector capabilities.
Accessible informa- Provides FDDILink module product information that can be accessed via
tion on the EEPROM the monitor utility or user interface.
Interface speed 25 MHz.
Controller speed 12.5 MHz.
Clocks 25 MHz symbol clock rate.
12.5 MHz byte clock rate.
Laser safety Single- and mixed-mode FDDILink modules are certified Class 1 laser
safe.
