PXM Gate 4 DMX RDM Manual

Hide thumbs Also See for Gate 4 DMX RDM:
Table of Contents

Advertisement

Quick Links

Download this manual
PX724
Gate 4
DMX RDM
MANUAL
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gate 4 DMX RDM and is the answer not in the manual?

Questions and answers

Related Manuals for PXM Gate 4 DMX RDM

Summary of Contents for PXM Gate 4 DMX RDM

  • Page 1 PX724 Gate 4 DMX RDM MANUAL...

  • Page 2: Table Of Contents

    10. Technical Data......................Declaration of conformity....................Manufacturer reserves the right to make modifications in order to improve device operation. tel.: (12) 385 83 06 PXM Marek Żupnik spółka komandytowa fax: (12) 626 46 94 Podłęże 654 E-mail: info@pxm.pl 32-003 Podłęże Internet: www.pxm.pl...

  • Page 3: General Description

    1. GENERAL DESCRIPTION Gate 4 DMX RDM is a gate that converts Art-Net signals to four output DMX-RDM ports. The gate offers two modes of merging signals from two sources: HTP and LTP. The protocol version used is Art-Net 4.

  • Page 4: Gate Construction

    3. GATE CONSTRUCTION The PX724 gate is equipped with one Ethernet port, four DMX512 outputs, a display, programming buttons, a ON/OFF power switch and LED indicators. FRONT OF THE DEVICE PREV ESCAPE ENTER NEXT display LED indicators on/off power switch programming buttons DEVICE REAR PANEL output for connecting...

  • Page 5: Description Of Information Parameters

    4.2. Description of information parameters The PX724 provides you with the following device information. PX724 GATE 4 DMX gate model, current IP address (DHCP or static). *192.168.1.14 If an address is provided by DHCP, an asterisk is added NEXT S/N: 17090001 gate serial number and version number of the software installed VER: 0.01 4.3.

  • Page 6: Port Settings

    4.4. Art-Net configuration PX724 GATE 4 DMX *192.168.1.14 NEXT ENTER ENTER ENTER ART-NET CONFIG. PORT 1 UNIVERSE UNIVERSE -> 0x0000 -> 0x0000 0x0000] NEXT ENTER NEXT UNIVERSE SWITCH UNIVERSE SWITCH 0x0] NEXT PORT 3 0x0000 -> ENTER MERGE MODE MERGE MODE [LTP] NEXT NEXT...
  • Page 7 page 6 ENTER DMX PARAMETERS BREAK TIME -> 176µs ENTER [UNIVERSE SWITCH] - universe number in the Art-Net NEXT protocol (range 0-15 dec, 0x0-0xF hex). Individual BREAK TIME [176µs] setting of a Universe switch value for a given port. It is a component of the entire Universe number for the MAB TIME 12µs...
  • Page 8 page 6 ENTER NET SWITCH NET SWITCH 0x00 0x00] NEXT ENTER SUBNET SWITCH SUBNET SWITCH 0x0] NEXT ENTER ENTER ART-NET TIMEOUT STOP DMX SIGNAL STOP DMX SIGNAL [Off] NEXT STOP DMX SIGNAL NEXT [On] ENTER TIMEOUT VALUE TIMEOUT VALUE 255s [255s] NEXT TIMEOUT VALUE...

  • Page 9: Presets Menu

    4.5. Presets menu The gate comes with 2 predefined standard sets of factory settings. In addition the user can save four own sets of parameters. After you enter the preset selected, all the parameters saved in it can be displayed. There is also an option allowing users to save their presets PX724 GATE 4 DMX [SAVE THIS PRESET].

  • Page 10: Information Communicated By Led Indicators

    5. INFORMATION COMMUNICATED BY LED INDICATORS In order to enable the backlight feature again, you need to press any of the buttons. The indicator diodes on the front panel of the gate provide information on the status of the unit: The four upper LEDs are bi-colour ones ( blue orange...

  • Page 11: Art-Net Commands

    6. ART-NET COMMANDS List of Art-Net commands supported in PX724: Name Value OpPoll 0x2000 OpPollReply 0x2100 OpOutput / OpDmx 0x5000 OpSync 0x5200 OpAddress 0x6000 OpTodRequest 0x8000 OpTodData 0x8100 OpTodControl 0x8200 OpRdm 0x8300 OpFirmwareMaster 0xf200 OpFirmwareReply 0xf300 OpIpProg 0xf800 OpIpProgReply 0xf900 7.

  • Page 12: Connecting Your Gate

    8. CONNECTING YOUR GATE power supply 230 V AC 230V AC 9. DIMENSIONS...

  • Page 13: Technical Data

    10. TECHNICAL DATA - DMX-RDM lines: - DMX line optical isolation: - overvoltage protection: - Art-Net version: Art-Net 4 - communication method: Art-Net protocol, display and buttons - RDM protocol support: - option to turn on filter packets other than DMX512: - verification of Art-Net packets sequence: - “No signal Art-Net”...

  • Page 14: Declaration Of Conformity

    DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże We declare that our product: Product name: Gate 4 DMX RDM Product code: PX724 smeets the requirements of the following standards as well as harmonised standards: PN-EN 50581:2013,...

This manual is also suitable for:

Px724
