Summary of Contents for PXM Gate 4 DMX RDM
- Page 1 PX724 Gate 4 DMX RDM User manual...
-
Page 2: Table Of Contents
8 Upgrade.....................22 9 Connection scheme.................24 10 Dimensions.....................25 11 Technical data..................26 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 Firm. 1.08 32-003 Podłęże mail: info@pxm.pl Rev.1-4... -
Page 3: Description
Description Gate 4 DMX RDM is a gate that converts Art-Net signals to four output DMX-RDM ports. From software version 1.01, the device also allows conversion of DMX512 signal to Art-Net. The device is designed do run from 230V AC mains. This gate has a solid, metal housing protecting against mechanical damage. -
Page 4: Safety Conditions
Safety conditions Gate PX724 is powered directly from standard 230V AC grid what can cause electric shock when safety rules are not observed. Therefore it is necessary to observe the following: 1. Installation, particularly power connection, should be performed by a person holding the appropriate qualifications, according to instruction manual. -
Page 5: Connectors And Control Elements
11. Clean with damp cloth only – gate should be cut off from power supply. Connectors and control elements Front of the device: DMX 1 DMX 2 DMX 3 DMX 4 ACTIVITY LINK LED indicators display programming buttons on / off power switch Device rear panel: output for connecting DMX Neutrik... -
Page 6: Programming The Device
Programming the device 4.1 Button features (escape) - allows you to exit the parameter being programmed ✕ without saving any changes or to move to a higher menu level ↓ (next) - moves you back through the menu or decreases values being set ↑... -
Page 7: Description Of Information Parameters
4.2 Description of information parameters The PX724 provides you with the following device information, such as: • gate model and current IP address (if an address is provided by DHCP, an asterisk * is added) gate serial number and version number of the software installed •... -
Page 8: Dmx In / Out Port Settings
ENTER PX724 G4 DMX RDM 2.139.178.116 2 x NEXT ENTER ENTER Network config. IP address IP address -> 2.139.178.116 [2].139.178.116 NEXT ENTER Subnet mask Subnet mask 255.0.0.0 [255].0.0.0 NEXT ENTER Gateway address Gateway address 2.0.0.1 [2].0.0.1 NEXT ENTER DHCP DHCP [Off] NEXT DHCP... -
Page 9: Art-Net Configuration In Mode Art-Net
→ 4.5 Art-Net configuration in mode Art-Net Below is a diagram showing the [ART-NET config.] menu and a description of individual parameters that can be changed depending on the user's needs. ENTER PX724 G4 DMX RDM 2.139.178.116 3 x NEXT ENTER ENTER ENTER... - Page 10 previous page previous page ENTER ENTER DMX parameters Break time -> 176us ENTER Net switch Net switch NEXT 0 0x00 [0 0x00] Break time NEXT [176us] ENTER ENTER Subnet switch Subnet switch MAB time 0 0x0 [0 0x0] 12us NEXT NEXT ENTER ENTER...
- Page 11 S: (Sub-Net switch) sub-net number in the Art-Net protocol • (range 0 – 15 dec, 0x0 – 0xf hex) U: Universe switch • Using [Universe] you can change all 3 universe number components (Net switch, Sub-Net switch and Universe switch). There is a possibility of quick preview from the main menu of Universes assigned to a given port, the diagram below: ENTER...
- Page 12 with RDM protocol support [Auto discovery]. The device automatically searches when the device is started up. [DMX Parameters] – configuration of DMX parameters for a given port, times: [Break time] – duration of a low state along the line at the beginning of •...
-
Page 13: Art-Net Configuration In Mode Dmx Art-Net
→ 4.6 Art-Net configuration in mode DMX Art-Net In the PX724 gate in the mode of converting the signal from DMX512 to → Art-Net after the change of [Direction] in the chosen port on DMX Art-Net, the configuration of [RDM] and [DMX parameters] disappears, and the [Transmission] parameter appears in their place, in which options are available: [Unicast] –... -
Page 14: Presets Menu
ENTER PX724 G4 DMX RDM 2.139.178.116 3 x NEXT ENTER ENTER ENTER ART-NET config. Port 1 Universe Universe -> -> 0 0x0000 0 0x0000 [0 0x0000] NEXT ENTER Universe switch Universe switch 0 0x0 [0 0x0] NEXT ENTER Direction (in) Direction (in) DMX ->... -
Page 15: Settings For The Other Parameters
4.8 Settings for the other parameters The miscellaneous sub-menu [Miscellaneous] allows you to turn on [On] or off [Off] the screen saver [Screensaver]. After 15 seconds the display and the all the indicator LEDs will be turned off. The device will continue to operate, without any interruption of the other parameters. -
Page 16: Information Communicated By Led Indicators
Information communicated by LED indicators The indicator diodes on the front panel of the gate provide information on the status of the unit: The four upper LEDs are bi-color ones (blue – orange) and communicate the status of DMX-RDM. Each diode is assigned to one of the four DMX ports. - Page 17 Additional information communicated by the LED indicators: if the screen saver mode is enabled or an “Art-Net Mute Indicators” • command has been received, all the diodes go out if the gate receives an “Art-Net Indicate” command, all the diodes start •...
-
Page 18: Px724 Cooperation With The Grandma2 Console
PX724 cooperation with the grandMA2 console The PX724 gate can work with the grandMA2 console, however, support for devices supporting the RDM protocol requires changing the console settings. To operate RDM devices, the settings must be changed in the gate [Auto discovery] on enabled, the gate will continuously search for RDM devices. - Page 19 [ETHERCON 2 (ETH1)] connector with the IP address set so that the console is in the same network as the gate. If Gate 4 DMX RDM is on the 2.x.x.x network with the mask of 255.0.0.0, then for the device to work together, the console must be on the same network.
- Page 20 If everything is correctly configured, the gate continuously searches for the devices supporting the RDM protocol, the console is in the same network as the gate and has enabled RDM and Art-Net Output Active support. After adding the main RDM window to the main scree, you should see a list of all devices that supported the RDM protocol:...
-
Page 21: Art-Net Commands
Art-Net commands List of Art-Net commands supported in PX724 Name Value OpPoll 0x2000 OpPollReply 0x2100 OpOutput / OpDmx 0x5000 OpSync 0x5200 OpAddress 0x6000 OpInput 0x7000 OpTodRequest 0x8000 OpTodData 0x8100 OpTodControl 0x8200 OpRdm 0x8300 OpFirmwareMaster 0xf200 OpFirmwareReply 0xf300 "Art-Net™ Designed by and Copyright Artistic Licence Holdings Ltd”... -
Page 22: Upgrade
Upgrade In order to update the gate firmware, use the program DMX-Workshop, which is available on the Artistic Licence website: http://www.artisticlicence.com Firmware updates are available on the manufacturer's website. 1. In the main menu field select the option [Node List] 2. -
Page 24: Connection Scheme
Connection scheme power supply 230V AC 230V AC → Example of connecting a device operating in DMX512 mode Art-Net → (on the left) and Art-Net DMX512 (on the right): Router / switch 230V AC 230V AC Driver controller e.g PX333 Driver... -
Page 25: Dimensions
10 Dimensions... -
Page 26: Technical Data
11 Technical data type PX724 DMX/RDM lines DMX/RDM input socket 3-pin or 5-pin Neutrik XLR RDM protocol support bi-directional signal conversion optically isolated XLR connectors galvanic isolated XLR connectors Ethernet connector type Neutrik etherCON DHCP protocol support Art-Net version Art-Net 1, 2, 3, 4 communication method Art-Net, display and buttons firmware update... - Page 27 Podłęże, 05.11.2021 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Gate 4 DMX RDM Product code: PX724 meets the requirements of the following standards, as well as harmonised standards:...
