Devatec ElectroVap KIT MC Series Technical Handbook

Electrode steam humidifier
Hide thumbs Also See for ElectroVap KIT MC Series:

Advertisement

Quick Links

TECHNICAL HANDBOOK
ELECTRODE STEAM HUMIDIFIER
Humidificateur vapeur à électrodes
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ElectroVap KIT MC Series and is the answer not in the manual?

Questions and answers

Related Manuals for Devatec ElectroVap KIT MC Series

Summary of Contents for Devatec ElectroVap KIT MC Series

  • Page 1 TECHNICAL HANDBOOK ELECTRODE STEAM HUMIDIFIER Humidificateur vapeur à électrodes...

  • Page 2: Table Of Contents

    KIT MC LECTRO Contents Safety information Product accreditation RoHS declaration Delivery contents Dimensions & Weight KIT MC component parts Installation Step 1 - Installation 10-14 Step 2 - Water connection 15-16 Step 3 - Electrical installation 17 to 27 Maintenance Cylinder maintenance guideline Cleaning the steam cylinder Cleaning the valves...

  • Page 3: Safety Information

    Delivery and storage Any loss or damage during delivery should be reported to carrier by registered letter within 3 working days and be advised to devatec or to authorized dealer. It is recommended that the ElectroVap KIT MC humidifier be kept in its transit packaging for as long as possible prior to maintenance.
  • Page 4 KIT MC LECTRO Safety information ENERAL This manual contains all details necessary for the planning and installation of the ElectroVap KIT MC humidifier. In addition commissioning and maintenance details are included. The manual is intended for use by engineers and properly trained technical personnel. Maintenance, servicing or repair work must only be carried out by suitable skilled and qualified personnel, the customer must be responsible for ensuring their suitability.

  • Page 5: Product Accreditation

    EN 60204-1 : Safety of machinery – Electrical Equipment of machines – Part 1 : General requirements EN 292 Parts 1 & 2 : Safety of machinery basic principle mechanical design. Manufacturer’s Name and Address DEVATEC SAS Bd des Frères Rousseau 76550 Offranville - FRANCE...

  • Page 6: Rohs Declaration

    KIT MC LECTRO RoHS declaration devatec sas Bd des Frères Rousseau 76550 Offranville France Confirms that the ElectroVap KIT MC steam humidifier is manufactured in compli- ance withhe European regulations 2002/95/EU (RoHS). This guideline regulates after July 1 2006 the use of mercury, cadmium, lead (soldering processes), chrome VI as well as PBB and PBDE.

  • Page 7: Delivery Contents

    Any loss or damage during delivery should be reported to carrier by registered letter within 3 working days and be advised to devatec or to authorized dealer. It is recommended that the ElectroVap KIT MC humidifier be kept in its transit packaging for as long as possible prior to maintenance.
  • Page 8 KIT MC LECTRO Dimensions & Weight KIT MC 40 to 60 KIT MC 5 to 30 Dimensions in mm Weight in Kg Steam Drain Water Steam Drain Humidifier outlet outlet inlet outlet outlet spacing Empty Opera spacing -ting Model KIT MC 5 to 15-2 178,5 KIT MC 20 to 30 178,5...

  • Page 9: Kit Mc Component Parts

    KIT MC LECTRO KIT MC component parts Example : KIT MC 5 to 30 Bracket (lower) Drain valve Steam cylinder Cylinder holding spring Bracket (upper) Filling cup Inlet valve Main electronic board (Ref: 500102) High water level electrode wire 10 Power electrode wire (x3)
  • Page 10 When in operation, the rear panel becomes hot (60°C) so do not hang the humidifier on a heat sensitive surface. The devatec humidifiers have been developped to be hanged on wall. Before installation,  make sure that the surface material is strong enough to hold the humidifier.
  • Page 11 KIT MC LECTRO Installation - Step 1 Dimensions for wall bracket mounting KIT MC 5 to 15-2 KIT MC 20 to 30 3 05 8 trou s O 6,5 8 trous O 6,5 Precise wall installation is required to ensure full efficiency of the humidifier.
  • Page 12 KIT MC LECTRO Installation - Step 1 continued KIT MC 40 to 60 61 0 1 6 trous O 6,5 Precise wall installation is required to ensure full efficiency of the humidifier.
  • Page 13 Any loss or damage during delivery should be reported to carrier by registered letter within 3 working days and be advised to devatec or to authorized dealer. Unpack the humidifier from its carton box, take the steam cylinder off the bracket and lay it gen-...
  • Page 14 KIT MC LECTRO Installation - Step 1 Pick up the cylinder, tilt it a little to engage the steam outlet inside the retaining spring. Lift the cylinder upward, put the drain outlet facing the drain valve body and push downward to fit it into it. For KIT MC 40 to 60, install the second cylinder the same way.

  • Page 15: Step 2 - Water Connection

    (please refer to the softener’s user manual). Duplex softeners are best suited to your humidifier in this regard. In doubt, please consult devatec. Demineralised water: this is a water treatment by reverse osmosis or running through resins.
  • Page 16 KIT MC LECTRO Installation - Step 2 Steam ouput The connection to the steam outlet should be made with a Ø 25 or 40 mm steam hose as per the model of humidifier. To prevent steam leakage, it must be tightened with the supplied clamp.
  • Page 17 KIT MC LECTRO Installation - Step 3 ECOMMANDATIONS : All works concerned with the electrical installation must be carried out by skilled and qualified personnel (eg electrician with appropriate training). The customer is responsible for ensuring their suitability. Please observe local regulations concerning the provision of electrical installations.
  • Page 18 KIT MC LECTRO Installation - Step 3 KIT MC steam humidifier in 3 X 380V - 50/60 Hz Production Imaxi Pmaxi Steam Torroidal KIT MC Cylinder size (KG/St) ( A ) ( A ) ( KW ) diameter transformer Small Loop Small Straight through...
  • Page 19 KIT MC LECTRO Installation - Step 3 KIT MC steam humidifier in 3 X 415V - 50/60 Hz Production Imaxi Pmaxi Steam Torroidal KIT MC Cylinder size (KG/St) ( A ) ( A ) ( KW ) diameter transformer 4,26 Small Loop 6,60...
  • Page 20 KIT MC LECTRO Installation - Step 3 KIT MC steam humidifier in 3 X 460V - 50/60 Hz Production Imaxi Pmaxi Steam Torroidal KIT MC Cylinder size (KG/St) ( A ) ( A ) ( KW ) diameter transformer 4,25 Small Loop 6,61...
  • Page 21 KIT MC LECTRO Installation - Step 3 Proportional control and remote information board wiring scheme ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 22 KIT MC LECTRO Installation - Step 3 KIT MC2 5 wiring scheme - 3x380-400-415V + N ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 23 KIT MC LECTRO Installation - Step 3 KIT MC2 5 wiring scheme - 3 x 440-460-480V + N ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 24 KIT MC LECTRO KIT MC2 8 to 20 wiring scheme - 3x380-400-415V + N ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 25 LEC- KIT MC2 30 wiring scheme - 3x380-400-415V + N ALL WORKS...
  • Page 26 KIT MC LECTRO Installation - Step 3 KIT MC2 40 wiring scheme - 3x380-400-415V + N ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 27 KIT MC LECTRO Installation - Step 3 KIT MC2 50-60 wiring scheme - 3x380-400-415V + N ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL...
  • Page 28 KIT MC LECTRO Cylinder maintenance guide for tap or hard waters Estimated cylinder maintenance curve X= Humidifier steam demand 300 H 800 H 1000 H 2000 H 4000 H Working hours Example given: it is recommended to maintain (if cleanable type) or change (if disposable type) the steam cylinder every 800 to 900 hours of operation for a humidifier running at full capacity and using a water of TH20.
  • Page 29 KIT MC LECTRO Maintenance - Cleaning of steam cylinder The KIT MC humidifiers are currently fitted with disposable cylinder(s).The latter can however be easily substitued for cleanable type at customer’s choice. REPLACING THE STEAM CYLINDER Drain the steam cylinder(s) fully using the manual drain key. Isolate the power both at the general switchboard and at the humidifier (rocker power switch).
  • Page 30 KIT MC LECTRO Maintenance - Valves NTRETIEN DE LA VANNE DE VIDANGE The drain valve should be maintained whenever the steam cylinder is maintained or changed. Once the steam cylinder has been pulled out (please refer to the « cleaning of the steam cylinder » page ), disconnect the drain valve supply wires.
  • Page 31 KIT MC LECTRO Maintenance - Valves INLET VALVE MAINTENANCE The inlet valve should be maintained every 6 months as a minimum and after 50 hours operation. Isolate the water supply and remove the water supply hose from the valve. Disconnect the electrical wires from the coil. Untighten the collar clamp and remove the water feed hose.
  • Page 32 KIT MC LECTRO Maintenance - Spare parts list Code Description 930058 Filling cup with hoses for KIT MC 5 to 15-2 930059 Filling cup with hoses for KIT MC 20 to 30 930060 Filling cup with hoses for KIT MC 40 to 60 930080 Cylinder retaining clip for KIT MC cylinder 930136...
  • Page 33 KIT MC LECTRO Maintenance - Spare parts list Code Description 930190 Brass nut Ø 8mm 930301 Bag of 3 fibre washers 930211 High water level electrode + nut Ø 4mm Cylinder upper half—Please consult factory 930203 Bag of bolts & nuts KIT MC 5 to 15-2 (cleanable cylinder ) 930223 Bag of bolts &...
  • Page 34 KIT MC LECTRO Maintenance - Spare parts list Code Description 930010 Disposable cylinder KIT MC 5 to 15-2 930020 EA disposable KIT MC 5 to15-2 930028 Cleanable cylinder KIT MC 5 to 15-2 930037 EA cleanable cylinder KIT MC 5 to 15-2 Code Description 930014...
  • Page 36 76550 Offranville - France LR 94104-2 Export division: tel. +33 (0)2 35 83 06 44 or +33 (0)2 35 83 03 86 Email: export@devatec.com - www.devatec.com devatec reserves the right to change specifications or design of the equipments described in this borchure without prior notice.
