- Page 1 Technical manual Remote control ElectroVap MC2 Steam Bath Pictures for illustrating purposes only...
- Page 2 STEAM BATH MC REMOTE CONTROL Contents Description 3 - 4 Dimensions & Installation Electrical connections 6 to 8 Use & Settings 9 to 13 Pictures for illustrating purposes only...
- Page 3 STEAM BATH MC REMOTE CONTROL Description Steam Production Power On/Off Button Date / Time Access Setting Button Hammam light Power On/Off Button Remote Control On/Off Button 12 V Power Inlet Jack (for optional AC adaptor) Navigation Pad OK Button Pictures for illustrating purposes only...
- Page 4 STEAM BATH MC REMOTE CONTROL Description The Steam Bath MC Remote Control gives you distant control over your steam bath. Two models are available : Model 1 : includes the remote control, a 12V supply transformer, a 3 dry contact control board and a RS485 board.
-
Page 5: Dimensions & Installation
STEAM BATH MC REMOTE CONTROL Dimensions & Installation IMENSIONS • Weight = 370g INSTALLATION Remove the lateral screws of the Remote Control and dissemble the box. Set the bottom on wall at the desired place and mark one of the 4 holes. Drill a ø... - Page 6 STEAM BATH MC REMOTE CONTROL Electrical connexions The wiring of the equipment described under must be made with a 0.75 mm2 maximum flexible wire. STEAM BATH 12V TRANSFORMER Remote control board Ref: 500650/03 Transformer 220V/12V 100VA 220V • Attach the 230/12V transformer inside the electrical compartment of the steam generator Terminals on DIN with the supplied set of bolts and nuts.
- Page 7 STEAM BATH MC REMOTE CONTROL Electrical connexions The wiring of the equipment described under must be made with a 0.75 mm2 maximum flexible wire. RS485 board RS485 board Steam generator main board Ref: 500800/01 Ref: 500101/05 • Clamp the RS485 board onto the DIN rail of the steam generator.
- Page 8 3 CONTACT BOARD • Attach the 3 contact board onto the stand-offs located under the steam generator main board with DEVATEC M4 8mm long screws. Réf:500101-05 • Connect the grey ply of the 3 contact board to the connector X18 of the steam generator main board.
-
Page 9: Display Symbols
STEAM BATH MC REMOTE CONTROL Use & Settings DISPLAY SYMBOLS Steam generator in run Hammam lighting on Steam generator on halt Hammam lighting off 45°C Room temperature Perfume on Music (option) Pre-set temperature Auto-timer Steam generator on-line Steam generator off-line DISPLAY READING 45°C 45°C... -
Page 10: Auto Timer
STEAM BATH MC REMOTE CONTROL Use & Settings Day / time settings 45°C 45°C - Mo 00:00 Pressing button 2 highlights the day and hour information. Press the « OK » button and set the day by pressing the up or down arrows of the navigation pad. Then use the right side arrow for selecting the hour digits and set the time with the up and down arrows of the navigation pad. - Page 11 STEAM BATH MC REMOTE CONTROL Use & Settings Auto timer setting Mo Tu We Th Steam unit status 10:00 to 15:00 Working period time Th 15:12 2. The first day is illuminated : press the down arrow to select the humidifier status.
- Page 12 STEAM BATH MC REMOTE CONTROL Use & Settings Menu scrolling Temperature setting point Number of lamps 22°C 22°C 45°C - Mo 09:00 Mo 09:00 Perfume intensity Music on or off 22°C 22°C Mo 09:00 Mo 09:00 Pictures for illustrating purposes only...
- Page 13 STEAM BATH MC REMOTE CONTROL Use & Settings Option 1 setting Option 2 setting 22°C 22°C Opt 1 Opt 2 Mo 09:00 Mo 09:00 Option 3 setting Remote control nb (if several remote controls) 22°C 22°C Opt 3 Unit n° Mo 09:00 Mo 09:00 Pictures for illustrating purposes only...
- Page 14 Export Division: tel. +33 (0)2 35 83 06 44 ou +33 (0)2 35 83 03 86 fax. +33 (0)2 35 85 36 72 Email: export@devatec.com - www.devatec.com devatec reserves the right to change specifications or design of the equipment described in this borchure without prior notice.
