Page 3: Table Of Contents
Steam bath EG/HG Contents Safety information Product accreditation RoHS certification Split view of the unit Determination of the steam generator INSTALLATION Unit mounting Water connection Example of installation Dimensions Condensate draining ELECTRICAL INSTALLATION Electrical features Temperature sensor connection Steam bath EG Connecting the optional equipment Steam bath control panel 16-20... -
Page 4: Safety Information
ElectroVap MC Steam bath Safety information Important This section should be read carefully to ensure the safe and correct installation of your steam bath GENERAL This manual contains all details necessary for the planning and installation of the ElectroVap EG/HG steam bath. -
Page 5: Product Accreditation
EN 60204-1: Safety of machinery – Electrical Equipment of machines – Part 1: General requirements. EN 292 Parts 1 & 2: Safety of machinery basic principle mechanical design. Manufacturer’s Name and Address DEVATEC SAS Rue Saint Eloi 76550 Ambrumesnil - FRANCE... - Page 6 ElectroVap MC RoHS declaration DEVATEC SAS Rue Saint Eloi 76550 Ambrumesnil France Confirms that the ElectroVap ELMC steam humidifier is manufactured in compliance with the European regulations 2002/95/EU (RoHS). This guideline regulates after July 1 2006 the use of mercury, cadmium, lead (soldering processes), chrome VI as well as PBB and PBDE.
- Page 7 ALPHANUMERICAL POWER LAMP LCD PANEL CLEANABLE CYLINDER ELECTRICAL DIN RAIL COMPONENTS OUTLET VALVE INLET VALVE QUARTER TURN DOOR FASTENER IDENTIFICATION...
-
Page 9: Unit Mounting
ElectroVap MC Steam bath Unit wall installation Unit mounting Unpack the ELMC steam bath generator and check for any damage. Damage to packing and/or unit must be reported by registered letter to carrier within 3 working days. Provide free space all around the unit : 1 m. to 1.20 m. (3 to 3 ft.) from the floor to the bottom of the steam generator, 1.25 m. -
Page 10: Water Connection
The water supply must be made without any additional chemicals (chlorine, disinfectant, ozone). Also some water qualities may generate foam causing disturbances with the correct control of the humidifier. Please refer to Devatec technical services for further assistance. The water level must be between (a) -
Page 11: Example Of Installation
ElectroVap MC Steam bath EG/HG Example of a Hammam installation... -
Page 12: Dimensions
ElectroVap MC Steam bath EG/HG ELMC 5-8-10 Dimensions ELMC 10 (230 V single phase)-15-20-30 ELMC 40-50-60 ELMC 90... -
Page 13: Condensate Draining
The drain operates under gravity only. Ensure drain pipework has a pitch of at least 15°C to allow the unit to drain efficiently. The Devatec recommended steam hoses should be used for connecting the humidifier to the drain network. Regular replacement is recommended. -
Page 14: Electrical Installation
Steam bath EG/HG Electrical installation All works concerned with the electrical installation must be carried out by skilled and qualified personnel (eg electrician with appropriate training). The customer is responsible for ensuring their suitability. Please observe local regulations concerning the provision of electrical installations. Check all electrical terminal screws at commissioning, after 50 hours operation and at every service thereafter. - Page 15 ElectroVap MC Electrical installation The tables below show the electrical features of the ElectroVap ELMC steam bath generators. In all cases, the electrical supply of the command circuit is in 230 V. single phase. ELMC STEAM BATH IN 2 X 230 VAC 50/60Hz Pmaxi Ø...
- Page 16 Wiring the temperature sensor A lll works concerned with electrical installation must be carried out by a skilled and qualified personnel.
-
Page 17: Steam Bath Control Panel
STEAM BATH CONTROL PANEL 130mm 45°C Thickness : 35mm 180mm LCD display conntrol box for the close or remote control . To stop steam production within the hammam, press the bottom of the steam bath control box but do not turn off the ON/OFF switch of the generator. This cabinet must be connected directly to the ELMC EG steam bath. - Page 18 103 mm 4 X screws + pegs (supplied) 45°C 4 SCREWS (4 X 10) Make the wiring as follows DEVATEC -Green wire on terminal n° 1 REF 500700/01 -Brown wire on terminal n° 2 -Blue wire on terminal n° 3 -Ground wire on terminal n°4...
- Page 19 Connection of the front control panel & the temperature sensor 45°C SCHAFT SEAL BLACK BROWN BLUE 12V FOR GREEN LIGHITING WHITE 220V FOR Jumper or safety control SCENT DISPENSOR INSULATED WIRE COMMON 5 6 5 5 5 4 5 3 5 1 5 0 4 9 4 8 47 DIN RAIL ELMC STEAM BATH...
-
Page 20: Steam Bath Hg
Front panel identification Indications on the display panel : Temperature within the steam bath. Temperature within the steam Light ON/OFF bath. 45°C inication in the Variation of the steam bath. temperature. Steam production indicator. Steam production stopped. Light is OFF 'ELMC EG is stopped. - Page 21 Modifications of the setting points Modification of the temperature setting point : Push on the enter button the display indicates the temperature of the set point inside the steam bath. You can change it with the help of the buttons ( + ) or ( - ). DO NOT FORGET TO PRESS THE ENTER KEY TO CONFIRM THE SETTING 45°C 60°C...
-
Page 22: Connecting The Optional Equipment
Connecting the optional equipment Brown 3 wire White temperature sensor Green Blue white DEVATEC Réf:500101-05 Type: The connection of the temperature sensor is to be made directly on terminal block X4 on terminals 17, 16 & 15 Transformer 220V/ 12V 100 VA... -
Page 23: Temperature Sensor
Temperature sensor Dimensions: ø Drilling hole 26 mm 60,5mm 3 holes of 3,2mm for installing 55,5mm Wiring : The connection of the temperature sensor is to be made directly onto the main board with a three pin connector (s.a. page 15 for further reference). Position of the temperature sensor : Recommended position Vertical position... -
Page 24: Steam Nozzle
Steam nozzle Dimensions of the nozzle: 60mm Material : PTFE food 1" 45mm 60mm Dimensions of the steam nozzle union : 90mm in standard, 120mm out standard (upon request) 40mm 30mm Material : PTFE food 1" 25mm 40mm Dimensions of the nut: 1"1/4Gaz Build up and example of the installation of the whole steam nozzle: Steam nozzle union... - Page 25 Wiring the main board and the optional equipment ALL WORKS CONCERNED WITH ELECTRICAL INSTALLATION MUST BE CARRIED OUT BY A SKILLED AND QUALIFIED PERSONNEL.
-
Page 26: Perfume Dispensor
Perfume dispensor Dimensions : Perfume pump 7 liters tank Coil & perfume dispensor valve Inlet of rislan pipe no-return 4/6mm. valve. Copper coil 10mm. Brass connection of the steam hose 25mm/ 40mm Ø 40mm 204mm Ø 25mm 80mm Material : Polyethylen high density, food quality. -
Page 27: Disinfecting System
Disinfecting system Dimensions : Disinfecting pump 7 liters tank Disinfecting nozzle Lock nut 1". Drilling 33mm for wall. 7mm maxi 82mm 204mm 80mm Material : High density Ø 47mm polyethylen - food quality. Wiring diagram : TERMINALS ON THE DIN RAIL OF THE STEAM BATH Equipment supplied :... - Page 28 Disinfection system How to start the disinfection system : To adjust the disinfection time : Please check with menu "Changing parameters" DISINFECTION TIME: 30 SEC on page 32. To initiate the disinfection system : Press simultaneously on the disinfection time begins to scroll (s.a.
-
Page 29: Front Panel Identification
ElectroVap MC Front panel identification Software assistant Alpha digital display Changing program Scrolling program Scrolling program Manual draining Steam production light ON/OFF Switch Power light Identification tag... - Page 30 ElectroVap MC EG/HG commissioning Software assistant Checking and Switching on 1 - After completion of the installation inspection, switch on the water supply to the unit.. 2 - Switch on the main power supply. 3 - The power lamp must be illuminated. 4 - Switch on the main power supply I/0 on I.
- Page 31 Changing parameters menu to change menu Roll up or down the menu in pushing on keys, press the select button Menu : CHANGING DATA SYSTEM With the steam bath switched on, press the key until the Changing system parameters menu ENTER ACCESS CODE : is displayed.
- Page 32 Changing parameter menu Take care: Rolling the menu in pushing on , pressing the select button in any time, allow to change the menu CONTACTOR STOP WHEN DRAINING this function enable to choose between an AJUSTEMENT KG/ST adjustment by evaporation (for DI water) PER : or by draining.
-
Page 33: User Information Menu
USER INFORMATION MENU Take care : Rolling the menu in pushing on , pressing the select button in any time, allow to change the menu. Menu :USER INFORMATION STEAM BATH ELMC Indicates the ELMC steam bath model. STEAM PRODUCED : Indicates the nominal steam ST/H production of the steam bath. - Page 34 USER INFORMATION MENU Take care : Rolling the menu in pushing on , pressing the select button in any time, allow to change the menu. Indicates the steam production time PRODUCT BEFORE before maintenance, allows to planify CLEAN KG/ST the cylinder maintenance. NEXT SERVICE DUE Indicates the time running period between two maintenance intervals.
-
Page 35: Status Menu
STEAM BATH STATUS MENU Take care : Rolling the menu in pushing on , pressing the select button in any time, allow to change the menu. Menu :STEAM BATH STATUS CONTROL SIGNAL Indicates the control used STEAM BATH (°C) TOTAL STEAM RUN KG/VAP Total steam production since the <... -
Page 36: Alerts
ElectroVap MC ALERTS Software assistant P ALERTS TROUBLE CAUSES / ACTIONS OPTION Check power supply, fuses Power phase or power circuit breaker detection device is P0 ALERT A power phase is missing (general power switchboard) required F1 fuse (2A) or contactor Unit on steam demand coil failure. -
Page 37: Maintenance
ElectroVap MC Inspection maintenance Maintenance The ElectroVap Steam Bath MC is delivered with disposable cylinder(s) in standard which can be replaced by cleanable ones, however, without any modification, according to the choice of the user. Drain the steam cylinder using the manual drain key. -
Page 38: Valves Maintenance
ElectroVap MC Valves maintenance Maintenance Drain valve maintenance Drain the steam cylinder fully and remove it from the humidifier. Isolate power and water supply before To be made at each cylinder attempting to carry out any maintenance. • Remove the cap from, the end of the solenoid valve 1 maintenance •... - Page 39 Notes ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 40 33 (0)2 35 83 03 86 Fax : 33 (0)235 85 36 72 www.devatec.com Email : export@devatec.com DEVATEC continues to develop its products For this reason, the technical data and specifications of the products can be changed without prior notice. Rev. 2.4 - 19/01/11...
