Mode Description; I/O Functions; Quadrature Input - Teknic CLEARPATH MCVC Series User Manual

C P M C / S D U
L E A R A T H
Q I
UADRATURE NPUT
M D
ODE ESCRIPTION
Stepper Replacement
Signal Function
Input A Speed & Dir
Input B Speed & Dir
Enable Enable
Trigger NA
cc_mcsd
B "leads" A for CCW motion
Input A
Input B
Step and Direction Inputs and Timing
I/O F
UNCTIONS
T , I .
EKNIC NC
M R
S E R A N U A L E V
You send 2-channel quadrature signals and ClearPath moves in response.
This mode is great for replacing quadrature driven stepper systems with a
single compact device that costs less and does more.
To get started, select "Quadrature" from the Input Format drop down
menu in the Mode Controls section.
Assert the Enable Input to energize the motor. Then, send quadrature
pulses from an external controller to ClearPath Inputs A and B to
command motion.
Quadrature Signal Control
Input Type
Pulse: Quadrature A
Pulse: Quadrature B
Logic: High=Enable Low=Disable
NA
Enable Input - Asserting this input energizes the motor shaft.
Input A - Quadrature A input.
Input B - Quadrature B input.
Output (HLFB) - See HLFB section for available modes.
Notes:
•
Input B must lead Input A for CCW motion; Input A must lead
Input B for CW motion.
•
Maximum pulse input frequency = 700kHz per channel at 50%
duty cycle.
. 3 . 0 9
Available on
SDSK + SDHP
Example Timing
1
0
1
0
1
0
1
0
v
ccw
Motor velocity vs. time
A "leads" B for CW motion
Input A
Input B
1 5 3
Direction
changes
t
cw
