Planar UltraRes X Series User Manual
020-1396-00A
User Manual
®
UltraRes
TM
X Series
URX75-ERO-T
URX85-ERO-T
URX100-ERO
URX100-ERO-T
URX75
URX75-ERO
URX85
URX85-ERO
URX100
Page | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraRes X Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Planar UltraRes X Series

Summary of Contents for Planar UltraRes X Series

  • Page 1 User Manual ® Planar UltraRes X Series URX75 URX75-ERO URX75-ERO-T URX85 URX85-ERO URX85-ERO-T URX100 URX100-ERO URX100-ERO-T Planar UltraRes X Series User Manual Page | 1 020-1396-00A...
  • Page 2 When you purchase a Planar product, you get more than a display; you get the service and support you need to maximize your investment. To find the latest warranty and service information regarding your Planar product, please visit http://www.planar.com/support...

  • Page 3: Table Of Contents

    Cleaning the Display ......................10 Unpacking and Checking Accessories..............11 Package Contents ......................11 Accessory Kit ........................12 Planar UltraRes X Series – Standard Inputs ..............13 Installing the Display ....................15 Mounting with a VESA Mount ...................16 Installing the Optional Planar Profile Mounting System ............17 Using the Lifting Eyes ..................25...
  • Page 4 19.3 Uninstalling the MultiTouch Driver ..............71 Planar UltraRes X Series Remote Monitoring Software ........... 72 Remote Monitoring Home ....................72 Remote Monitoring System Information ................72 Remote Monitoring Inputs and Views ................73 Remote Monitoring Audio ....................74 Remote Monitoring Presets ....................75 Remote Monitoring Panel Brightness and Power .............76 Remote Monitoring Notifications ..................77...

  • Page 5: Introduction

    Introduction The Planar® UltraRes X™ Series is a line of 75", 85" and 100" 4K resolution (3840 x 2160) professional LCD displays with 700-nit brightness and wide color gamut perfect for High Dynamic Range (HDR) content. The displays offer superior visual performance with multi-source viewing and advanced processing ideal for applications ranging from collaborative meeting spaces to high-impact digital signage and media rooms.

  • Page 6: Safety Information

    Safety Information Before using the Planar UltraRes X Series, please read this manual thoroughly to help protect against damage to property, and to ensure personnel safety. • Be sure to observe the following instructions. • For your safety, be sure to observe ALL the warnings detailed in this manual.

  • Page 7: Important Safety Instructions

    9. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles and the point where they exit from any Planar large format LCD display. 10. Only use the attachments/accessories specified by the manufacturer.

  • Page 8: Recommended Usage

    • 85": URX85, URX85-ERO, URX85-ERO-T • 100": URX100, URX100-ERO, URX100-ERO-T Planar recommends turning off the power for 4 hours per day for optimal performance. For complete warranty details, please visit http://www.planar.com/warranty. Planar UltraRes X Series User Manual Page | 8...

  • Page 9: Important Waste Disposal Information

    • 75" and 100" Planar UltraRes X Series models: 0-40°C at up to 3000 meters • 85" Planar UltraRes X Series models: 0-40°C at up to 1500 meters and 0-35°C at up to 3000 meters Cooling Requirements For optimal performance, active cooling by the installer should be planned for when the ambient temperature anywhere in the wall is predicted to be above the specified ambient temperature for the display.

  • Page 10: Cleaning The Display

    • Do not let cleaner seep into the display, as it may cause electrical shock or damage. • Refer to the Planar Display Cleaning Guidelines for more information. Planar UltraRes X Series User Manual Page | 10 020-1396-00A...

  • Page 11: Unpacking And Checking Accessories

    Service service mode and locking Brackets the panel in place when (optional) installed. Planar For use when installing UltraRes X Planar UltraRes X Profile Profile Mounts. Mount Install Template (optional) Planar UltraRes X Series User Manual Page | 11 020-1396-00A...

  • Page 12: Accessory Kit

    Planar® Annotation and TouchMark™ whiteboarding software Single (touch models only) License Key Card Quick Start Guide: Planar UltraRes X Series and Planar QE Series Displays Planar UltraRes X Series User Manual Page | 12 020-1396-00A...

  • Page 13: Planar Ultrares X Series - Standard Inputs

    Planar UltraRes X Series – Standard Inputs OPS: 4K/60Hz Note: Only one HDCP 2.2 source can be displayed at a time. If HDMI 1 and HDMI 2 are both being shown on the display at the same HDMI 1: HDMI, 4K/60Hz, HDCP 2.2 time, only HDMI 1 will support HDCP 2.2 content.
  • Page 14 RS232 LINE AUDIO OUT USB-A USB-B DB9 (Female) 2.5mm TRS (Female) SPDIF AUDIO Planar UltraRes X Series User Manual Page | 14 020-1396-00A...

  • Page 15: Installing The Display

    Installing the Display Before installation, keep the following points in mind: • The Planar UltraRes X Series displays are heavy. Be sure that the structure has adequate design to support the weight of each display to be mounted. • Be sure the structure the unit will be mounted to is sufficiently engineered to support the total weight of the display and any peripheral equipment that may be attached to the display.

  • Page 16: Mounting With A Vesa Mount

    The mount must be secured to the Planar UltraRes X Series display using the four M8- 1.25 VESA mounting locations, and 10mm -15mm thread engagement is required for secure mounting.

  • Page 17: Installing The Optional Planar Profile Mounting System

    Installing the Optional Planar Profile Mounting System For Planar Profile kits, a template has been supplied in the kit to simplify installation of the Planar Profile components. If the template has been misplaced or lost, refer to the product outline drawing for pertinent dimensions on the location of the Planar Profile mount component locations.
  • Page 18 2. Using the dimensions on the template for the model being installed, mark the location of the upper-left mount position. 3. Install the left mount as indicated. The marked position is the location of the center hole on the mount. Planar UltraRes X Series User Manual Page | 18 020-1396-00A...
  • Page 19 1 are correct. A slight variation in this location is okay due to being able to slightly move the display horizontally once installed. Planar UltraRes X Series User Manual Page | 19 020-1396-00A...
  • Page 20 7. Level and install the main support screws. At minimum, two pieces of mounting hardware must be used on a single hanging mount component. 8. Place template vertically on either hook of the installed hanging mounts. Planar UltraRes X Series User Manual Page | 20 020-1396-00A...
  • Page 21 Note: The “V” notch in the template labeled for the model being installed can be used to verify the center marks made in step 1 are correct. 10. Remove the template and repeat steps 8-9 for the other hanging mount. Planar UltraRes X Series User Manual Page | 21 020-1396-00A...
  • Page 22 Note: Two of the side mount attachment locations are slotted, in case when the panel is installed there needs to be a slight vertical adjustment in location. 12. Release the locking tabs on the service mounts so they do not interfere with the display installation. Planar UltraRes X Series User Manual Page | 22 020-1396-00A...
  • Page 23 Note: It is recommended that capable lift equipment be used to install the displays due to their weight. Planar provides lifting eyes (sold separately) for use with capable equipment (see “Using the Lifting Eyes” on page 25). If mechanical equipment is unavailable or impractical, Planar supplies lifting straps for use with lifting displays.
  • Page 24 Rotate the kickstand down after pulling the panel out. The kickstands will nest into the lower panel mount brackets. Caution: Use both kickstands. Using only one will cause stresses in the panel that can cause damage. Planar UltraRes X Series User Manual Page | 24 020-1396-00A...

  • Page 25: Using The Lifting Eyes

    For a single point lifting application, the angle of the line between the eyehooks and the display must be 45° or greater. 3. Lift the panel into place. 4. Remove the lift mechanism attached to the lifting eyes. Planar UltraRes X Series User Manual Page | 25 020-1396-00A...

  • Page 26: Cable Length Recommendations

    DisplayPort length is 3m for DisplayPort 1.2 and 5m for DisplayPort 1.1. HDMI cable length is recommended as follows: • 4K @ 50/60Hz: 5m maximum • 4K @ 24/25/30Hz: 15m maximum • 1080p @ 60Hz and lower resolutions: 30m maximum Planar UltraRes X Series User Manual Page | 26 020-1396-00A...

  • Page 27: Installing Ops Expansion (Optional)

    10. Installing OPS Expansion (Optional) Planar UltraRes X Series displays are equipped with an expansion slot that supports the Intel® Open Pluggable Specification (OPS). The slot will support OPS devices such as PC’s, SDI modules, HDBaseT receivers, etc. To install an OPS device, remove the protective cover on the display and slide the device firmly into position.

  • Page 28: Operating The Display

    OSD Keypad Buttons Descriptions Power Power on/Power off  Menu Left/Decrease value  Menu Right/Increase value  Menu Up/Increase volume  Menu Down/Decrease volume Menu/Exit Menu/Exit Source Source selection (toggle) Planar UltraRes X Series User Manual Page | 28 020-1396-00A...

  • Page 29: Remote Control Receiver

    The remote control receiver is located near the keypad on the rear of the display. Use the IR extender cable for operating the remote from the front of the display. IR Sensor Planar UltraRes X Series User Manual Page | 29 020-1396-00A...

  • Page 30: Led Indicators

    Installations where the display is tilted downward or upward at an angle may also be prone to these issues and are not recommended. Note: Failure to follow these instructions will void the warranty. Planar UltraRes X Series User Manual Page | 30 020-1396-00A...

  • Page 31: Using The Remote Control

    16. Using the Remote Control Below is a picture of the remote control and its corresponding Hex codes. See the following page for button descriptions and Hex codes. Planar UltraRes X Series User Manual Page | 31 020-1396-00A...

  • Page 32: Ir Command Protocol

    The carrier frequency is 38 kHz, with the modulated pulses having a 33% duty cycle. • Commands are sent at a maximum rate of 9 Hz. For example, below is the NEC control code for the ON button of the Planar UltraRes X Series remote control (assuming the default address is used). Binary...
  • Page 33 Number button 9 1785 0x06F912ED Number button 0 VOL + 1785 0x06F91CE3 Volume increase VOL - 1785 0x06F921DE Volume decrease MUTE 1785 0x06F920DF Audio mute COLOR 1785 0x06F913EC Not used Planar UltraRes X Series User Manual Page | 33 020-1396-00A...
  • Page 34 Selects HDMI 4 for the current zone 1785 0x06F92DD2 Selects DP for the current zone 1785 0x06F92ED1 Not used 1785 0x06F92FD0 Not used 1785 0x06F930CF Selects OPS for the current zone Planar UltraRes X Series User Manual Page | 34 020-1396-00A...

  • Page 35: Locking The Keypad And Ir Remote

    The IR remote code set transmitted by the remote and accepted by the display can be configured. This is useful if there are multiple Planar displays and you would like each remote to work only with one of the displays. It can also be used if IR interference with another device, such as a DVD player, is occurring.

  • Page 36: Turning The Display Off

    Note: The analog audio out is variable. S/PDIF is fixed. 17.7 Selecting Layouts and Input Sources With Planar MediaPlex Plus Processing, you can show one source at a time or multiple sources simultaneously. Multiple layout options are available and can be selected from the Inputs and Views Menu (see page 36).

  • Page 37: Navigating Through The Menus

    3. Press PREV on the remote control, or MENU on the keypad, to return to the previous menu. To exit the menu system, press MENU on the remote control, or continue to press menu on the keypad until the main menu is reached. Planar UltraRes X Series User Manual Page | 37 020-1396-00A...

  • Page 38: Inputs And Views Menu

    Options: HDMI 1, HDMI 2, HDMI 3, HDMI 4, DP, OPS; Default: HDMI 3 • Note: If HDMI1 was selected as another source, OPS cannot be selected. If OPS was selected as another source, HDMI1 cannot be selected. Planar UltraRes X Series User Manual Page | 38 020-1396-00A...
  • Page 39 Select from four PiP (Picture-in-Picture) layouts. The layout in orange will be the active layout displayed when the Multi-Source View is set to PiP. PIP Size • Select the size of the PiP (Picture-in-Picture) window. Planar UltraRes X Series User Manual Page | 39 020-1396-00A...

  • Page 40: Image Adjust Menu

    The current zone can be changed via the menu or by using the ZONE 1-4 keys on the remote control. • Note: Changing the Current Zone setting via the ZONE 1-4 keys also changes the Audio Select setting. Planar UltraRes X Series User Manual Page | 40 020-1396-00A...
  • Page 41 Green Gain • Adjust the green gain of the image • Range: 0~200; Default: 100 Blue Gain • Adjust the blue gain of the image • Range: 0~200; Default: 100 Planar UltraRes X Series User Manual Page | 41 020-1396-00A...
  • Page 42 Move the image horizontally or vertically. The amount to move is measured in input pixels. • Range: -1000~1000; Default: 0 Revert to Defaults • Reset all settings in the Image Adjust menu to their factory defaults for the current zone only Planar UltraRes X Series User Manual Page | 42 020-1396-00A...

  • Page 43: Audio Menu

    • Note: This setting applies only to the internal speakers, and cannot be adjusted for the Line Out connector. Balance • Set the audio balance • Range: 0~100; Default: 50 Planar UltraRes X Series User Manual Page | 43 020-1396-00A...

  • Page 44: Presets Menu

    • Range: Preset 1~Preset 10 Save • Save the current setup for later recall • Range: Preset 1~Preset 10 Delete • Delete the selected preset • Range: Preset 1~Preset 10 Planar UltraRes X Series User Manual Page | 44 020-1396-00A...

  • Page 45: Advanced Settings Menu

    Range: 0~100; Default: 75 Local Dimming • Turn on or off the local dimming function, if supported by the display • Options: On, Off; Default: On • Note: 75” and 85” models only Planar UltraRes X Series User Manual Page | 45 020-1396-00A...
  • Page 46 • Note: When Wake On Signal is selected, the LAN port and Remote Monitoring web interface will remain accessible after the display enters sleep mode. Planar UltraRes X Series User Manual Page | 46 020-1396-00A...
  • Page 47 When enabled, the system will wait for an indication from the OPS module that it has finished its power down sequence, before going into the standby state specified in Power Down Mode • Options: Disable, Enable; Default: Enable Planar UltraRes X Series User Manual Page | 47 020-1396-00A...
  • Page 48 Note: The specified DNS server is used when Use Network Time is checked for the Set Date and Time setting. DHCP • Turn DHCP on or off • Options: On, Off; Default: On Planar UltraRes X Series User Manual Page | 48 020-1396-00A...
  • Page 49 Blank Screen Color • Select the color to display when there is no signal in a zone • Options: Black, White, Gray, Red, Green, Blue, Cyan, Magenta, Yellow • Default: Black Planar UltraRes X Series User Manual Page | 49 020-1396-00A...
  • Page 50 Schedule Submenu Planar UltraRes X Series User Manual Page | 50 020-1396-00A...
  • Page 51 Action: The action to take for the event. Options are Turn On, Turn Off, Recall, Panel Brightness. • Data: The preset to recall when the Action is set to Recall, or the backlight setting when the Action is set to Panel Brightness. Planar UltraRes X Series User Manual Page | 51 020-1396-00A...
  • Page 52 Options: 4K60, 4K30, 1080P Horizontal Active • The number of active pixels in a line • Range: 0~4095 Vertical Active • The number of active lines in a field • Range: 0~4095 Planar UltraRes X Series User Manual Page | 52 020-1396-00A...
  • Page 53 • The number of line times in the vertical front porch • Range: 0~255 Vertical Sync Width • The number of line times in the vertical sync • Range: 0~255 Planar UltraRes X Series User Manual Page | 53 020-1396-00A...
  • Page 54 Multi-Source View mode and Advanced Layout setting (if applicable). Planar UltraRes X Series User Manual Page | 54 020-1396-00A...
  • Page 55 Cyan x • Adjust the x coordinate of the cyan color point • Range: 0.000-0.800 Cyan y • Adjust the y coordinate of the cyan color point • Range: 0.000-0.800 Planar UltraRes X Series User Manual Page | 55 020-1396-00A...
  • Page 56 Copy the color coordinate settings for the current zone and the current Color Gamut setting to all other zones Revert to Defaults • Reset the color coordinate settings for the current zone and the current Color Gamut setting to their default values Planar UltraRes X Series User Manual Page | 56 020-1396-00A...
  • Page 57 Tiling Submenu This menu contains controls for using multiple Planar UltraRes X Series displays in a tiled configuration. This is useful when trying to display one image across multiple displays. In addition to setting up the width and height of the tiled wall, each display must have its position within the tiled wall properly selected.
  • Page 58 Unit Row 2 Unit Column 3 Unit Column 2 Unit Column 1 Unit Row 1 Unit Row 1 Unit Row 1 Unit Column 3 Unit Column 2 Unit Column 1 Planar UltraRes X Series User Manual Page | 58 020-1396-00A...
  • Page 59 Unit Row 1 Unit Column 3 Unit Column 3 Unit Column 3 Unit Row 3 Unit Row 2 Unit Row 1 Unit Column 4 Unit Column 4 Unit Column 4 Planar UltraRes X Series User Manual Page | 59 020-1396-00A...
  • Page 60 Unit Row 3 Unit Column 2 Unit Column 2 Unit Column 2 Unit Row 1 Unit Row 2 Unit Row 3 Unit Column 1 Unit Column 1 Unit Column 1 Planar UltraRes X Series User Manual Page | 60 020-1396-00A...
  • Page 61 Examples" on page 62. • Options: Disable, Enable; Default: Disable Frame Width, Frame Height • Selects how many lines/pixels are removed from the image to compensate for the display’s bezel Planar UltraRes X Series User Manual Page | 61 020-1396-00A...
  • Page 62 Frame Compensation Examples Below are examples with the Frame Compensation feature enabled (left) and disabled (right). Note that the eagle’s eye is noticeably different when Frame Compensation is disabled. Planar UltraRes X Series User Manual Page | 62 020-1396-00A...
  • Page 63 This menu selects a test pattern to show on the display for diagnostic purposes. Test Patterns • Options: Black, Gray, White, Red, Green, Blue, Magenta, Yellow, Cyan, Gray Ramp, Red Ramp, Blue Ramp, Color Bar, Checkerboard Planar UltraRes X Series User Manual Page | 63 020-1396-00A...
  • Page 64 On: The display will force all content to be displayed in HDR mode. • Note: When viewing SDR content in this mode, the image quality will not have the correct appearance. Planar UltraRes X Series User Manual Page | 64 020-1396-00A...
  • Page 65 • Options: 1.1, 1.2; Default: 1.2 Keypad Lock • Lock or unlock the keypad. When it is enabled, all keypad presses will be ignored. • Options: Enable, Disable; Default: Disable Planar UltraRes X Series User Manual Page | 65 020-1396-00A...
  • Page 66 Options: 00000-65535; Default: 01785 Save All Settings to USB • Save all settings in the display to a USB flash drive. The saved file will be named Planar- settings.bin and will be saved in the root folder of the USB flash drive. •...

  • Page 67: Information Menu

    18.5 Information Menu System Information Submenu This menu displays version information for all programmable parts in the system. It also contains the model and serial number. Planar UltraRes X Series User Manual Page | 67 020-1396-00A...
  • Page 68 Image Information Submenu This menu displays image details for the current zone. If more than one zone is available, you can change zones by setting the Current Zone option. Planar UltraRes X Series User Manual Page | 68 020-1396-00A...
  • Page 69 Error Log Submenu This menu displays a chronological list of system errors that have occurred. For a list of possible errors, see "Error Codes" on page 101. Planar UltraRes X Series User Manual Page | 69 020-1396-00A...

  • Page 70: Using The Touch Screen

    You can use the touch screen to control your Windows, Mac, or Linux operating system. The Planar UltraRes X Series is HID compliant, delivering up to 12 points of touch on both Windows and Linux without a driver. To achieve greater than 12 points of touch on a Planar UltraRes X Series Touch display, a driver will need to be installed on the operating system.

  • Page 71: Uninstalling The Multitouch Driver

    19.3 Uninstalling the MultiTouch Driver 1. On the PC, select the Start menu, All Programs and the PQLabs Software. 2. Click on the MultiTouch Driver. 3. Select the Uninstall option. Planar UltraRes X Series User Manual Page | 71 020-1396-00A...

  • Page 72: Planar Ultrares X Series Remote Monitoring Software

    Remote Monitoring Software Planar UltraRes X Series Remote Monitoring is a software tool that displays information about the display via a web browser. It is used primarily to access the settings in the OSD as well as provides some additional features.

  • Page 73: Remote Monitoring Inputs And Views

    This page shows how the sources will be laid out on the screen based on the current Multi- Source View and Advanced Layouts selections. For the OSD equivalent, refer to "Inputs and Views Menu" on page 38. Planar UltraRes X Series User Manual Page | 73 020-1396-00A...

  • Page 74: Remote Monitoring Audio

    This page enables you to make audio adjustments to the selected zone. Note: Volume, Bass, Treble and Balance do not apply to the S/PDIF output. For the OSD equivalent, refer to "Audio Menu" on page 43. Planar UltraRes X Series User Manual Page | 74 020-1396-00A...

  • Page 75: Remote Monitoring Presets

    To save or overwrite a preset, enter the preset number to save or overwrite, optionally enter a custom name for the preset, and then click the Save button. For the OSD equivalent, refer to "Presets Menu" on page 44. Planar UltraRes X Series User Manual Page | 75 020-1396-00A...

  • Page 76: Remote Monitoring Panel Brightness And Power

    This page enables you to make adjustments to the brightness and power settings. For the OSD equivalents, refer to "Panel Brightness Submenu" on page 45 and "Power Submenu" on page 46. Planar UltraRes X Series User Manual Page | 76 020-1396-00A...

  • Page 77: Remote Monitoring Notifications

    Port: Selects the port that the SMTP server uses. • Authentication: Use Auto unless directed by your ISP or network administrator. • User Name: Login username for the SMTP server. Planar UltraRes X Series User Manual Page | 77 020-1396-00A...
  • Page 78 If the test email fails, you can use the View Last 10 Log Messages button to get more detailed information about the failure. Planar UltraRes X Series User Manual Page | 78 020-1396-00A...

  • Page 79: Remote Monitoring System Settings

    27. Remote Monitoring System Settings This page enables you to make adjustments to a variety of system settings. For the OSD equivalent, refer to "System Settings Submenu" on page 64. Planar UltraRes X Series User Manual Page | 79 020-1396-00A...

  • Page 80: Remote Monitoring Access Control

    With the exception of System Information, all functions listed above require User level access. If no password is set for either access level, all functions can be accessed. By default, there are no passwords for either access level. Planar UltraRes X Series User Manual Page | 80 020-1396-00A...

  • Page 81: External Control

    External Control In addition to using the Planar UltraRes X Series remote control and display, there are other methods of controlling the Planar UltraRes X Series display externally: • Using a serial link to send ASCII commands and to receive responses to those commands.

  • Page 82: Hdr

    To take full advantage of the benefits of expanded color gamut, bit depth and dynamic range, the Planar UltraRes X Series supports content encoded in HDR (High Dynamic Range). When HDR content is present, the image performance will expand beyond the capabilities of standard dynamic range content, allowing for a wider range of colors, bit depth and dynamic range.

  • Page 83: Signal Compatibility

    VESA DMT 1152x864 84.999 77.094 121.500 VESA DMT 1280x768 49.929 39.593 65.250 VESA CVT 1280x768 59.995 47.396 68.250 VESA CVT-R 1280x768 47.776 79.500 VESA CVT 1280x768 74.893 60.289 102.250 VESA CVT Planar UltraRes X Series User Manual Page | 83 020-1396-00A...
  • Page 84 146.250 VESA CVT 1920x2160 135.000 297.000 CEA-861-F, VIC 16, with vertical parameters doubled 2560x1440 59.951 88.787 241.500 VESA CVT-R 2560x1600 59.972 98.713 268.500 VESA CVT-R 3840x2160 52.438 209.750 VESA CVT-R Planar UltraRes X Series User Manual Page | 84 020-1396-00A...
  • Page 85 74.250 SMPTE 274M, CEA-861-F Format 33 1080p 33.750 74.250 SMPTE 274M, CEA-861-F Format 34 1080p 56.250 148.500 SMPTE 274M, CEA-861-F Format 31 1080p 67.500 148.500 SMPTE 274M, CEA-861-F Format 16 Planar UltraRes X Series User Manual Page | 85 020-1396-00A...
  • Page 86 3840x2160 67.500 297.000 CEA-861-F Format 96, 4:2:0 sub- sampling 3840x2160 135.000 594.000 CEA-861-F Format 96 3840x2160 67.500 297.000 CEA-861-F Format 97, 4:2:0 sub- sampling 3840x2160 135.000 594.000 CEA-861-F Format 97 Planar UltraRes X Series User Manual Page | 86 020-1396-00A...

  • Page 87: Color Subsampling Report

    YUV 4:2:0 Video Timing Input Supported Supported Supported Supported 4K @ 50/60 Hz 4K @ 50/60 Hz HDMI 1-2, OPS 4K @ 50/60 Hz HDMI 3-4 All Other Supported Timings Planar UltraRes X Series User Manual Page | 87 020-1396-00A...

  • Page 88: Power Consumption

    The power consumption values stated in the Specifications table are calculated under the typical conditions of viewing a single source with default settings. Due to the advanced capabilities of the Planar UltraRes X Series, and the widely variable power consumption of user-installed OPS devices, the total maximum power draw of Planar UltraRes X Series is influenced by several factors: •...

  • Page 89: Specifications

    DisplayPort 1.2, HDMI 2.0 x 2, HDMI 1.4 x 2, OPS HDCP 2.2 Yes (HDMI 2.0) Audio Output Line out, S/PDIF out Control and LAN RJ45, RS232 In, IR, Keypad, Planar® UltraRes X™ Series App Monitoring Planar UltraRes X Series User Manual Page | 89 020-1396-00A...
  • Page 90 URX85-ERO-T: 235 lbs URX100-ERO-T: 370 lbs (84 kg) (107 kg) (168 kg) Mounting Planar Profile Mounting Planar Profile Mounting System or VESA 600 mm x 400 System or VESA 400 mm x 400 mm Wall Mount Weight 15lb (6.8kg) Fanless Speakers...
  • Page 91 (0-40°C) at up to 1500 m (0-40°C) at up to 3000 m Min 32°F ~ Max 95°F (0-35°C) at up to 3000 m Humidity 20-85% RH Approvals FCC Class A, cTUVus, CE Planar UltraRes X Series User Manual Page | 91 020-1396-00A...

  • Page 92: Dimensions

    Dimensions 29. URX75 29.1 URX75 Standard Planar UltraRes X Series User Manual Page | 92 020-1396-00A...

  • Page 93: Urx75-Ero

    29.2 URX75-ERO Planar UltraRes X Series User Manual Page | 93 020-1396-00A...

  • Page 94: Urx75-Ero-T

    29.3 URX75-ERO-T Planar UltraRes X Series User Manual Page | 94 020-1396-00A...

  • Page 95: Urx85

    30. URX85 30.1 URX85 Standard Planar UltraRes X Series User Manual Page | 95 020-1396-00A...

  • Page 96: Urx85-Ero

    30.2 URX85-ERO Planar UltraRes X Series User Manual Page | 96 020-1396-00A...

  • Page 97: Urx85-Ero-T

    30.3 URX85-ERO-T Planar UltraRes X Series User Manual Page | 97 020-1396-00A...

  • Page 98: Urx100

    31. URX100 31.1 URX100 Standard Planar UltraRes X Series User Manual Page | 98 020-1396-00A...

  • Page 99: Urx100-Ero

    31.2 URX100-ERO Planar UltraRes X Series User Manual Page | 99 020-1396-00A...

  • Page 100: Urx100-Ero-T

    31.3 URX100-ERO-T Planar UltraRes X Series User Manual Page | 100 020-1396-00A...

  • Page 101: Troubleshooting During Installation

    This section includes troubleshooting information about different issues you may encounter during the installation process or after your display has been running for some time. If you are not able to solve your issue in this section, please contact Planar’s Technical Support team for assistance.

  • Page 102: Symptoms, Possible Causes And Solutions

    33. Symptoms, Possible Causes and Solutions Below are different symptoms that you might encounter as you install your Planar UltraRes X Series display. First look at the different symptoms to see if you can find your issue. And then look at the possible cause and try the suggested solution(s).

  • Page 103: Symptom: Can't Get Pc To Output 4K @ 24/30/60 Hz

    Single, and you select OPS in a zone, any zones that are showing HDMI 1 will automatically change to OPS. Conversely, if you select HDMI 1 in a zone, any zones that are currently showing OPS will automatically change to HDMI 1. Planar UltraRes X Series User Manual Page | 103 020-1396-00A...

  • Page 104: Symptom: Ir Isn't Working Properly

    Reposition the display so it is vertical to slightly tilted back. Possible Cause There are items blocking the IR sensors from emitting or receiving Solution Clean display and sensor windows around the display. Planar UltraRes X Series User Manual Page | 104 020-1396-00A...

  • Page 105: Accessing Planar's Technical Support Website

    • User Manual • RS232 User Manual • Outline drawings • Standard warranties • Planar support hotline number and email • Firmware (contact Planar support via email or phone) Planar UltraRes X Series User Manual Page | 105 020-1396-00A...
