Page 4: Rs232 Communication
RS232 Setup The use of RS232 requires the display’s Power Down Mode to be in Networked Standby or Fast Startup. See the “Power Down Mode” section of the Planar UltraRes W Series User Manual. The RS232 connection must use the following settings: •... -
Page 5: Connecting The Rs232 Cable
Connecting the RS232 Cable The Female DB9 connector is wired as a Straight Through serial connection. Pin # Signal Receive Data (RD) Transmit Data (TD) Ground Planar UltraRes W Series RS232 User Manual Page | 5 020-1421-00A... -
Page 6: Rs232 Command Protocol
• Note that enumerated and integer values can be written either in decimal or hexadecimal. For example, a decimal value of ‘50’ can be written in hexadecimal as ‘0x32’. Planar UltraRes W Series RS232 User Manual Page | 6 020-1421-00A... -
Page 7: Protocol Encoding
Example command with multiple modifiers, multiple operators and different separators between the modifiers and operators (sets Red Gain to 104, Green Gain to 105 and Blue Gain to 106, on Zone 1) Planar UltraRes W Series RS232 User Manual Page | 7 020-1421-00A... - Page 8 Name containing “ and \ and \\” and \\” power.on.delay = .1 POWER.ON.DELAY:0.1 Example of a fixed point operand. Sets the Power On Delay to 0.1 seconds. Planar UltraRes W Series RS232 User Manual Page | 8 020-1421-00A...
-
Page 9: Rs232 Codes
ASPECT=AUTO • ‘!’ in the Operators column indicates that the command accepts the execute operator, which uses no operator symbol. The ‘!’ symbol is not included in the command. Planar UltraRes W Series RS232 User Manual Page | 9 020-1421-00A... - Page 10 1 = ZONE.2 Internal Speakers On] AUDIO.VOLUME, AUDIO.SETTINGS=2 51 52 53 54 0 AUDIO.TREBLE, Ops 2-8: Unsigned AUDIO.BASS, Integers AUDIO.SETTINGS:2 51 52 53 54 0 AUDIO.BALANCE, AUDIO.MUTE, AUDIO.SPEAKERS Planar UltraRes W Series RS232 User Manual Page | 10 020-1421-00A...
- Page 11 5 = YELLOW 6 = WHITE 7 = BLACK Brightness BRIGHTNESS =?+- 0-100 [For Zone 1] See Main -> Image Adjust BRIGHTNESS(ZONE.1)=50 -> Brightness. BRIGHTNESS(ZONE.1):50 [For the current zone] BRIGHTNESS=55 BRIGHTNESS:55 Planar UltraRes W Series RS232 User Manual Page | 11 020-1421-00A...
- Page 12 See Main -> Information sampling SUBSAMPLING 0 = ZONE.1 COLOR.SUBSAMPLING(ZONE.1)? -> Image Information -> 1 = ZONE.2 COLOR.SUBSAMPLING(ZONE.1):" Color Subsampling. 255 = CURRENT 4:4:4" [For the current zone] COLOR.SUBSAMPLING? COLOR.SUBSAMPLING:"4:2:0" Planar UltraRes W Series RS232 User Manual Page | 12 020-1421-00A...
- Page 13 34 for operands. Layout 2 = P.UL.2 3 = P.UR.1 4 = P.UR.2 5 = P.LL.1 6 = P.LL.2 7 = P.LR.1 8 = P.LR.2 9 = D.L.1 10 = D.L.2 Planar UltraRes W Series RS232 User Manual Page | 13 020-1421-00A...
- Page 14 [None = Current (for value] Settings -> Network -> reads only] NETWORK.DNS1? DNS Server. [None = STATIC (for NETWORK.DNS1:"172.16.0.140" writes only] [Write the DNS server 1 for static IP] NETWORK.DNS1(STATIC)="8.8.8.8 " NETWORK.DNS1(STATIC):"8.8.8.8" Planar UltraRes W Series RS232 User Manual Page | 14 020-1421-00A...
- Page 15 See Main -> Advanced CONNECTOR 2 = HDMI.2 HDMI.1 Settings -> EDID -> 3 = HDMI.3 EDID.SELECTEDCONNECTOR: Selected Connector. 4 = HDMI.4 HDMI.1 5 = DP 6 = ALL 13 = DP.2 Planar UltraRes W Series RS232 User Manual Page | 15 020-1421-00A...
- Page 16 Red Gain = 101, Green Gain time. three operands: = 102, Blue Gain = 103] Red Gain: 0-200 GAIN=101 102 103 Green Gain: 0-200 GAIN=101 102 103 Blue Gain: 0-200 Planar UltraRes W Series RS232 User Manual Page | 16 020-1421-00A...
- Page 17 HDMI CEC commands. HDMI CEC CEC.STANDBY 5018 =? 0 = OFF CEC.STANDBY=OFF See Main -> Advanced Power Off 1 = ON CEC.STANDBY:OFF Settings -> HDMI CEC Power Off Planar UltraRes W Series RS232 User Manual Page | 17 020-1421-00A...
- Page 18 [Write the DNS server 1 for static IP] NETWORK.DNS1(STATIC)="192.16 8.12.12" NETWORK.DNS1(STATIC):"192.16 8.12.12" IR Code IR.CODE 1210 =?+- 0-65535 IR.CODE=12345 See Menu -> Advanced IR.CODE:12345 Settings -> System Settings -> IR Remote ID Code. Planar UltraRes W Series RS232 User Manual Page | 18 020-1421-00A...
- Page 19 Settings -> Menus and 2 = GERMAN Messages -> Language 3 = SPANISH 4 = ITALIAN 5 = CHINESE. SIMPLIFIED 6 = CHINESE. TRADITIONAL 7 = PORTUGUESE 8 = JAPANESE Planar UltraRes W Series RS232 User Manual Page | 19 020-1421-00A...
- Page 20 Multi- MULTI.VIEW =?+- 0 = SINGLE MULTI.VIEW=DUAL See Main -> Inputs and Source 1 = DUAL MULTI.VIEW:DUAL Views -> Multi-Source View 4 = PIP View. Planar UltraRes W Series RS232 User Manual Page | 20 020-1421-00A...
- Page 21 String NETWORK. 1214 =? String NETWORK.NTPSERVER="pool.ntp. Selects the NTP server to Server NTPSERVER org" be used with the Use NETWORK.NTPSERVER:"pool.ntp. Network Time setting. org" Default = "0.pool.ntp.org". Planar UltraRes W Series RS232 User Manual Page | 21 020-1421-00A...
- Page 22 ORIENTATION 1302 =?+- 0 = LANDSCAPE ORIENTATION=LANDSCAPE See Main -> Advanced Rotation 1 = PORTRAIT ORIENTATION:LANDSCAPE Settings -> Menus and Messages -> OSD Rotation. Planar UltraRes W Series RS232 User Manual Page | 22 020-1421-00A...
- Page 23 1 = MEDIUM PIP.SIZE:MEDIUM Views -> Multi-Source 2 = LARGE View -> Advanced Layouts -> PIP Size. PIP Swap PIP.SWAP PIP.SWAP See IR remote control key PIP.SWAP@ACK PIP SWAP. Planar UltraRes W Series RS232 User Manual Page | 23 020-1421-00A...
- Page 24 See Main -> Presets -> Delete PRESET.DELETE(4) Delete. PRESET.DELETE(4)@ACK Preset Full PRESET.FULL 2004 ? 1-60 0 = NO PRESET.FULL(4)? Indicates whether data 1 = YES PRESET.FULL(4)=YES has been saved in the selected preset. Planar UltraRes W Series RS232 User Manual Page | 24 020-1421-00A...
- Page 25 Sets the name listed for Name PRESET.NAME(4)="Hello" the preset in the Delete, PRESET.NAME(4):"Hello" Recall and Save menus. Default = "Preset n", where 'n' is the preset number (e.g. "Preset 4") Planar UltraRes W Series RS232 User Manual Page | 25 020-1421-00A...
- Page 26 [For the current zone] REVERT.IMAGE.SETTINGS REVERT.IMAGE.SETTINGS@ACK RS232 RS232.LOCK 5022 =? 0 = DISABLE RS232.LOCK=ENABLE See Menu -> Advanced Lock 1 = ENABLE RS232.LOCK:ENABLE Settings -> System Settings -> Security -> RS232 Lock Planar UltraRes W Series RS232 User Manual Page | 26 020-1421-00A...
- Page 27 See Main -> Advanced Frequency FREQUENCY 1-20 1 = WEEKLY Daily] Settings -> Schedule -> 2 = WEEKDAYS SCHEDULE.FREQUENCY(3)= Set Event 1-20 -> 3 = WEEKENDS DAILY Frequency. SCHEDULE.FREQUENCY(3):DAILY Planar UltraRes W Series RS232 User Manual Page | 27 020-1421-00A...
- Page 28 Software -> Notifications Address NETWORK.SMTP.FROM:"myemail -> Email From Address. address@comcast.net" SMTP NETWORK. 1225 =? String NETWORK.SMTP.PASSWORD= See Remote Monitoring Password SMTP. "mypassword" Software -> Notifications PASSWORD NETWORK.SMTP.PASSWORD: -> Password. "mypassword" Planar UltraRes W Series RS232 User Manual Page | 28 020-1421-00A...
- Page 29 15 = USBC SOURCE.SELECT:HDMI.2 Splash SPLASH. 1305 =?+- 0 = DISABLE SPLASH.SCREEN=ENABLE See Main -> Advanced Screen SCREEN 1 = ENABLE SPLASH.SCREEN:ENABLE Settings -> Menus and Messages -> Allow Splash Screen. Planar UltraRes W Series RS232 User Manual Page | 29 020-1421-00A...
- Page 30 - POWERING.DOWN: The system is transitioning from the ON state to the STANDBY state. - FAULT: A system failure has occurred. Use the Error Log command to get more information. Planar UltraRes W Series RS232 User Manual Page | 30 020-1421-00A...
- Page 31 1 = TUE TIME.DAY:TUE Settings -> Schedule -> 2 = WED Set Date and Time -> 3 = THU Day. 4 = FRI 5 = SAT 6 = SUN Planar UltraRes W Series RS232 User Manual Page | 31 020-1421-00A...
- Page 32 TINT=55 TINT:55 Tracking TRACKING 5001 =?+- 0-100 TRACKING=50 See Main -> Image Adjust TRACKING:50 -> Tracking Treble AUDIO.TREBLE 1005 =?+- 0-100 AUDIO.TREBLE=50 See Main -> Audio -> AUDIO.TREBLE:50 Treble. Planar UltraRes W Series RS232 User Manual Page | 32 020-1421-00A...
- Page 33 See Main -> Information Info 10 = VERSION. BUILD.INFO(PKG.VERSION):"1.0.6 -> System Information. SUBMCU 00" 11 = VERSION. NETUART Volume AUDIO.VOLUME 1006 =?+- 0-100 AUDIO.VOLUME=50 See Main -> Audio -> AUDIO.VOLUME:50 Volume. Planar UltraRes W Series RS232 User Manual Page | 33 020-1421-00A...
-
Page 34: Current Zone Layout
Lower Left Zone 2 P.LR.1 Lower Right Zone 1 P.LR.2 Lower Right Zone 2 D.L.1 Dual View Left / Right Zone 1 D.L.2 Dual View Left / Right Zone 2 Planar UltraRes W Series RS232 User Manual Page | 34 020-1421-00A... -
Page 35: Key
