- Page 1 USER MANUAL WEIGHT INDICATOR E-CHECK: STATIC OR DYNAMIC WEIGHT CONTROL ON BELT 3590EXT, CPWE series indicator E-CHECK_04_15.09_EN_U...
-
Page 2: Table Of Contents
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U INDEX 1. INTRODUCTION ................................. 4 2. MAIN TECHNICAL SPECIFICATIONS ..........................5 2.1 EXTRA ACCESSORIES............................... 6 2.2 SYMBOLS ..................................6 3. INSTALLATION .................................. 7 3.1 DRILLING TEMPLATE, CASE AND DIMENSION......................7 3.2 POWER SUPPLY & START-UP ..........................8 3.3 CONNECTION TO THE BATTERY POWERED PRINTER .................. - Page 3 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 13.3.1.5 IN MOTION WITH NO PHOTO CELL .................... 33 13.3.2 TOLERANCE CHECK ........................... 34 13.3.2.1 CHECKING WITH ARTICLE AND T1,T2,T3 TOLERANCE SETTING........... 35 13.3.2.2 CHECKING WITH ARTICLE AND MINIMUM AND MAXIMUM THRESHOLD SETTING ....35 13.3.2.3 CHECKING WITHOUT ARTICLE AND FAST MINIMUM AND MAXIMUM THRESHOLDS SETTING ..............................
-
Page 4: Introduction
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 1. INTRODUCTION This manual was created to help you install and learn all about the functional possibilities of the purchased indicator. Besides having the standard features of a high precision scale, the instrument manages static and dynamic weighing on belts. -
Page 5: Main Technical Specifications
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 2. MAIN TECHNICAL SPECIFICATIONS POWER SUPPLY - 8 ÷ 40 Vdc - 6 Vdc from external rechargeable battery (optional). MAXIMUM POWER 16 VA. OPERATING TEMPERATURE From -15 to +40 °C (from 5 to 104°F). CONVERTER 24-bit Sigma Delta. -
Page 6: Extra Accessories
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 2.1 EXTRA ACCESSORIES The indicator can be implemented with additional internal and external modules used to increase interfacing possibilities. For example, one can increase the number of usable outputs; one may connect various types of printers (in order to have a report of the weighs made) or one can connect a giant display in order to better see the weigh operations. -
Page 7: Installation
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 3. INSTALLATION 3.1 DRILLING TEMPLATE, CASE AND DIMENSION The weight indicator has an anodized aluminium case, whose external dimensions are shown in the figure. It should be mounted on a panel board respecting the safety norms. DRILLING TEMPLATE DIMENSION: 187,5mm x 91,5mm... -
Page 8: Power Supply & Start-Up
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 3.2 POWER SUPPLY & START-UP The indicator is powered with 8÷40 Vdc voltage or a 6 Vdc optional battery. For the connection to the power supply mains the safety norms must be respected including the use of a “clean” line without noise and interference caused by other electronic devices. -
Page 9: Connection To The Battery Powered Printer
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 3.3 CONNECTION TO THE BATTERY POWERED PRINTER In a system where the indicator is connected to a printer, both are battery powered, the printer is normally maintained in STAND-BY and powered only when a printout is needed. This function reduces the energy absorbed by the battery when the printer is not being used. -
Page 10: Function Panel Keys
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 4. FUNCTION PANEL KEYS In the following section, and later on in the manual, the keys’ functioning is described in accordance to how these are configured by factory. It is possible to customise the functionality of the keys through the << F.Keys >> step. Where it isn’t specified, the function is carried out with the weighing cycle disabled (see section “ENABLING / DISABLING THE WEIGHING CYCLE”). -
Page 11: 2Ndf" Key: Second Function Of The Keys
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U - If pressed for an instant, it executes the printing and the zeroing of the general total. - In the numeric or alphanumeric input phase, it selects the digit to be modified from left to right. -
Page 12: Disabling The Keyboard
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U moves the blinking cursor to the left or to the right. scrolls in one sense or the other the list of all the enterable characters (0, 1…9, A, B…Y, Z). Examples: To enter the letter “B”... -
Page 13: Direct Compilation Of Input Text
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U - Confirms the entered value. - Enters the displayed step Numeric and - Quick entry of a numeric and alphanumeric string: through the CAPS/LOCK or SHIFT key it is possible to alphanumeric switch from the capital letters to the lower case letters, and vice versa, or enter the second character keys, SHIFT corresponding to the key (for example ", %, &, /, ? ). -
Page 14: Display Functions
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 5. DISPLAY FUNCTIONS While weighing, the display is subdivided mainly in 3 sections, shown in the figure below: 1) WEIGHT 2) STATUS INDICATORS 3) DATA (one or two lines depending on the weight zoom function; see following section). ARTICLE TEST STOP BELT CPWE display... -
Page 15: Weight Zoom
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 5.1 WEIGHT ZOOM The zoom function allows to increase the size of the weight digits, in order to ease the reading from a distance; with the active zoom, the data is shown on a single line. STOP BELT Through the <<... -
Page 16: Battery Level Indication
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 5.2.1 BATTERY LEVEL INDICATION The indicator is able to recognise whether it is powered by mains or by battery, and indicate its charge level; to enable the battery level indication, one should configure the << Bt.Stat. >> step. The charge level is shown during weighing by the battery symbol. - Page 17 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U - Lot weighs total - Accumulated lot total T.WGH T.LOT 0.000Kg By linking the function to a direct key, see the << F.Keys >> step, it is possible to quickly recall a visualisation by digiting, with the numeric keyboard, the relative number and pressing the key linked to the function.
- Page 18 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U Lot weighs’ total. T. WGH: Accumulated lot total. T. LOT: 0.000Kg By linking the function to a single key, it is possible to quickly recall a visualisation, by digiting from the numeric keyboard, the relative number, and by pressing the key linked to the function. Furthermore, by linking the number of a specific visualization to the function (preamble function in the <<...
- Page 19 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U Notes: - Visualisation of default 1. - If in visualisation 1 in the place of the threshold values there are EEEEE, this means that the values of the selected article weight are not correct. - If in visualisation 3 in the place of the lot total, the EEEEE message appears, this means that the value exceeds the maximum number of digits shown by the instrument.
-
Page 20: System Status Visualisation
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 5.3.1 SYSTEM STATUS VISUALISATION Below there are the statuses shown on the display, in the visualisation of the SYSTEM STATUS. In order to select this visualisation, refer to the previous section. STATUS DESCRIPTION MOTOR ALARM Locked weighing cycle: the EMERGENCY / MOTOR LOCK input (IN.6) is active for a minimum time set in step <<... -
Page 21: Messages
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 5.4 MESSAGES While using the indicator, it is possible to incur into the following errors: INSIDE THE SET-UP OR MENU MESSAGE DESCRIPTION When carrying out the multirange or multidivisional calibration, the ranges have not been C.Er. - Page 22 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U IN WEIGHING MESSAGE DESCRIPTION WITH ZOOM NOT WITH ZOOM ACTIVE ACTIVE ARTICLE ART.NOT SELECTED If the tolerance check has been enabled, one should select an NOT SELECTED article in order to start the weighing cycle. This message indicates that no article has been selected EXECUTION EXECUTION AUTOZERO...
-
Page 23: Scale Zero Function
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 6. SCALE ZERO FUNCTION With the weighing cycle disabled (see section “ENABLING / DISABLING THE WEIGHING CYCLE”), keep the ZERO key pressed at length; the message "ZERO" appears on the LED display after which: - If the weight on the scale is included in the percentage configured in the <<... -
Page 24: Limitation Of The Tare Functions
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U CONDITIONS FOR AUTOMATIC UNLOCKING: In case of SEMIAUTOMATIC TARE, the net weight before unloading the scale may also be 0. In case of MANUAL OR CALCULATED TARE or FROM DATABASE, the net weight before unloading the scale must be of at least 2 stable divisions. - Page 25 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U To display the metric data: By pressing 2ndF + C the display will show “METROLOLOGIC INFORMATION”. The display will show the number of the scale, the type of displayed data (“MAX” for the capacity, “MIN” for the minimum weigh, “e”...
-
Page 26: Filling In The Input Text
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 10. FILLING IN THE INPUT TEXT The indicator offers the possibility of using 15 CONFIGURABLE INPUT TEXTS (for example LOT, OPERATOR, SHIFT, etc.) in the F.ModE → tXt step (TECH.MAN.REF.), each contains the following steps: - DESCRIPTION the heading of the input text, up to 16 characters. -
Page 27: Articles Database
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 11. ARTICLES DATABASE The indicator has a database in which it is possible to store up to 1000 articles having three descriptions of 20 characters; each article is linked to a storage number, from 0 to 999. The selected article is shown on the display during the weighing operations, and can be printed through the relative print block. -
Page 28: Modification
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U In fact, if one sets the “Enable” parameter << Rit.Esp. >> step (TECH.MAN.REF.), the instrument will adopt the expeller delay time of the selected article. "ANALOGUE OUTPUT": value which the analogue output takes on for this article, useful for adjusting the belt speed depending on the selected article (see section “ANALOGUE OUTPUT (OPTIONAL)”, TECH.MAN.REF.);... -
Page 29: Database Access Password
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 12. DATABASE ACCESS PASSWORD In the SETUP (<< dtb.PWD >> parameter) one can set a password for access to the databases. A password will be required only when one wants to insert, modify or delete an element of the file; for a moment the display shows the message USER-PRESS KEY;... -
Page 30: Description Of The Cycle Phases
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U NOTE: With consensus from downstream (IN 1 = 0Vdc) not excluded in the << diS.d.st >> step, all keys take on their functions and it’s possible to turn the instrument off only with the weighing cycle disabled. 13.3 DESCRIPTION OF THE CYCLE PHASES Once the cycle is enabled, the instrument enables the belts and is ready for the automatic acquisition of the weighs by following the phases described in the following sections. -
Page 31: In Motion With 1 Photo Cell
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 7 WEIGHT INDICATOR The cadence belt supplies the packs to the weighing belt with the possibility of managing their flow, as described in section “MANAGEMENT OF CADENCE PHOTOCELL AND BELT”. FUNCTIONING In the moment that the pack starts transiting on the weighing belt, in other words from the instant in which the pack presence photo cell is obscured, the instrument: 1) Waits for the positioning of the pack 2) Halts the weighing belt... -
Page 32: At Halt Without Photo Cells
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U On the weighing belt mounted on the scale, a photo cell is installed (the START one), for checking the presence of the object to be weighed and for the consequent start of the weighing operations; furthermore, a second photo cell is used (the STOP one), for checking the exit of the object to be weighed, and consequent end of the weighing operations. -
Page 33: In Motion With No Photo Cell
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 1. WEIGHING BELT 2. PLATFORM 3. EVACUATING BELT 4. WEIGHT INDICATOR FUNCTIONING The weigh starts when the pack is positioned on the belt. The instrument tests the presence of the pack through the leading edge of the weight, verifies if the weight variation obeys the conditions set in the configuration, TECH.MAN.REF., then starts to execute the operations useful for achieving the weigh: a) the eventual weigh time starts (configured in step <<... -
Page 34: Tolerance Check
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 1. WEIGHING BELT 2. PLATFORM 3. EVACUATING BELT 4. WEIGHT INDICATOR 5. CADENCE PHOTO CELL 6. CADENCE BELT FUNCTIONING The weigh starts when the pack is positioned on the belt. The instrument tests the presence of the pack through the leading edge of the weight, verifies if the weight variation obeys the conditions set in the configuration, TECH.MAN.REF., then starts to execute the operations useful for achieving the weigh: a) the eventual weigh time starts (configured in step <<... -
Page 35: Checking With Article And T1,T2,T3 Tolerance Setting
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U - IF THE WEIGHT IS WITHIN THE TOLERANCE INTERVAL, the instrument executes the following sequence of operations: Totalization Weigh result display Belt Stop (if set) Evacuation - IF THE WEIGHT IS NOT WITHIN THE TOLERANCE RANGE: the instrument executes the following sequence of operations: ... -
Page 36: Checking Without Article And Fast Minimum And Maximum Thresholds Setting
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U - by setting both the thresholds, the weight is within tolerance if its value is within the 2 thresholds - by setting the minimum threshold only (maximum threshold equal to zero), the weight is within tolerance if its value is between the minimum threshold and the full scale capacity. -
Page 37: Checking Quantities In Ml
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U : tolerance range WEIGHT < than (TARGET – T3) → 0 (TARGET – T3) ≤ WEIGHT < (TARGET - T2) → 0 (TARGET – T2) ≤ WEIGHT < (TARGET - T1) → 1 (TARGET - T1) ≤ WEIGHT ≤ (TARGET + T1) → 1 (Always at 1, not modifiable) (TARGET + T1) <... -
Page 38: Correction Of The Out Of Tolerance Weight
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 13.3.3 CORRECTION OF THE OUT OF TOLERANCE WEIGHT By enabling the correction of the weight, or the mandatory correction of the weight, in the << TYP.ESP >> step, if the weight is out of tolerance, the instrument stops automatically the weighing belt after the weigh. The alarm output OUT3 is also enabled for the set time (<<... -
Page 39: Totalization Of Only The Weighs Within Tolerance
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U NOTE: the scale totals (PARTIAL, GENERAL, GRAND TOTAL and LOT TOTAL), are not depending on the selected article. 13.3.4.1 TOTALIZATION OF ONLY THE WEIGHS WITHIN TOLERANCE By setting the tolerance check function it is possible to choose if only the weighs within the tolerances have to be totalized (see <<... -
Page 40: Ticket Progressive
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U independently to three total types (PARTIAL, GENERAL, and GRAND TOTAL), in other words, it is possible to print three different values which will be cleared with the clearing of the relative total. 13.3.4.5 TICKET PROGRESSIVE Through function 402, combinable with the desired key (<<... - Page 41 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U T.PES.00000001 totalized, in the check with or without article and setting of the minimum and maximum thresholds. UNDER Tmin < T1- T.WGH.00000001 T.WGH.00000001 The instrument has furthermore 7 tolerance outputs, in order to command, for example, an external traffic light, or a sorter. After the totalization procedure, the output corresponding to the tolerance level in which the weight is detected, is activated;...
-
Page 42: Stop And Restart Of The Belts
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 13.3.6 STOP AND RESTART OF THE BELTS Once the weight is totalized it could be necessary to stop (or leave stopped) the belts: a) after a weigh out of tolerance, to allow the manual expulsion (if the << TYP.ESP >> step); b) after every weigh, to allow eventual processings (by enabling the stop after the weigh stop in the <<... - Page 43 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U automatically, when the number of minutes (since last zeroing) set in the << 0.BELT >> step configured on TIME (TECH.MAN.REF.) have elapsed: if one sets the 0 value, the autozero never enters into function automatically; if one sets the n (>0) value, if the weight is different from 0, the instrument executes the autozero function.
-
Page 44: Cycle Lock And Interruption Of The Weigh (Non Weighed Pack)
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 13.4 CYCLE LOCK AND INTERRUPTION OF THE WEIGH (NON WEIGHED PACK) During the functioning it is possible that the cycle is locked during the weigh acquisition, by verifying one of the lock conditions described in the following sections. Once the system is restored, and the cycle is eventually re-enabled, the instrument verifies if the acquisition of the weigh was stopped before the lock and it executes the following operations: if the acquisition is not terminated:... -
Page 45: Management Of Cadence Photocell And Belt
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 1) the “NON WEIGHED PACK” message appears depending on the selected visualization (see section “MODIFICATION OF THE DISPLAYED DATA”); 2) a RESTART impulse is required to restart: the operator must remove manually the weight for the repositioning on the cadence belt, in order to acquire again the weight. -
Page 46: Printouts
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U Weight greater than the maximum Capacity + 9d or less than -100d, for a time greater than the value configured in step << W.UN.OV >> (only with time greater than 0). EMERGENCY / MOTOR LOCK input (IN6) active for a time greater than the value configured in step <<... - Page 47 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U format is printed. LOT TOTAL - Programmable printout - by pressing the 2ndF and F3 keys, or in alternative by pressing at length the RESET / RESTART button (IN.4), the LOT TOTAL is automatically cleared and the relative format is printed. RESULT OF THE CALCULATOR - Programmable printout - Once terminated the operation with “CALCULATOR”...
-
Page 48: Linking Of The Formats To The Print Functions
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 14.1 LINKING OF THE FORMATS TO THE PRINT FUNCTIONS Through function 200, combinable with the desired key (<< F.KEYS >> step, TECH.MAN.REF.), one accesses the linking of the print formats (configurable in the SetuP >> SeriAL >> Prn.FMt step TECH.MAN.REF.) to the 12 programmable print functions: Print function Linked format... -
Page 49: Quick Linking Of The Formats
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U in which: XX indicates the number of the function to which the print format is linked. Select the print function (for example S.F. 01) through the arrow keys and press the ENTER key ... -
Page 50: Totalization
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U IND.ART. 0 XL PACKAGE TARGET 5.000kg START DATE AND TIME 20/01/05 12:08:48 - - - - - - - - - - - - - - - - - - - - - - - - WEIGH 5.002kg 14.2.2 TOTALIZATION... - Page 51 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U Below are the standard printouts of the instrument: WEIGHS CYCLE REPORT WEIGHS CYCLE REPORT (WITH ACTIVE ARTICLE AND (WITHOUT ARTICLE AND TOLERANCE CHECK) TOLERANCE CHECK) REPORT START JOHN SMITH LTD. JOHN SMITH LTD. (WEIGHING CYCLE 157 INDEPENDENCE AVE.
- Page 52 3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U ARTICLE TOTAL PARTIAL TOTAL (<< Prn.F.5 >>) (<< Prn.F.6 >>) PART. T. 50.00kg JOHN SMITH LTD. GROS. PART. T. 50.00kg 157 INDEPENDENCE AVE. TARE PART. T. 0.00kg LONDON WGTS PART. T. ADD. PART. T. ART.
-
Page 53: Other Functions
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 15. OTHER FUNCTIONS 15.1 DIAGNOSTIC PERIPHERALS Through function 118 combinable with the desired key (<<F.Keys >> step, TECH.MAN.REF.), one enables the diagnostic peripherals function. The display shows: A.O. NOTE: If the expansion board is not present, 2 inputs and 4 outputs are displayed. -
Page 54: Calculator
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 15.3 CALCULATOR Through function 114 combinable with the desired key (<<F.Keys >> step, TECH.MAN.REF.), one enables the calculator function. ADDITION MULTIPLICATION SUBTRACTION Procedure: Enter the first value using the numerical keyboard. Press F1 to add, F2 to multiply, F3 to subtract the value. -
Page 55: Functioning With Alibi Memory
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 16. FUNCTIONING WITH ALIBI MEMORY The alibi memory allows storing the executed weighs or the weights transmitted to the PC. The stored values can then be recalled by the PC serial line or directly on the indicator’s display for a following check. The data filed with each weigh or upon each weight transmission is: Gross weight Tare... -
Page 56: Reading Of The Weighs Carried Out
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 16.1 READING OF THE WEIGHS CARRIED OUT Through function 418, combinable with the desired key (<< F.Keys >> step, TECH.MAN.REF.) it’s possible to read a carried out weigh, with weighing cycle disabled (see section “ENABLING / DISABLING THE WEIGHING CYCLE”): first enter the rewriting number of the Alibi memory (rEW.id), confirm with ENTER, and then enter the weigh number (id) and press ENTER. -
Page 57: String Format (Weight/Id)
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U The instrument shows the PIDM (weight/id) string described in the following paragraph. To avoid the saving of the same weigh various times, it is possible to use the <II>CIP<CRLF> command (see the description of the serial commands (TECH.MAN.REF.)), and the number of the last stored weigh and the last totalised weigh will be displayed. -
Page 58: Weigh Reading
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U 16.2.3 WEIGH READING Command: [II]ALRDXXXXX-YYYYYY <CR o CRLF> in which [II] 485 address (only in the case of 485 transmission mode) XXXXX rewriting number, from 0 up to 255. ASCII 045 character YYYYYY ID code <CR o CRLF>... -
Page 59: Declaration Of Conformity
3590EXT, CPWE series indicators E-CHECK_04 _15.09_EN_U DECLARATION OF CONFORMITY This device conforms to the essential standards and norms relative to the applicable European regulations. The Declaration of Conformity is available in the web site www.diniargeo.com WARRANTY The instrument has a TWO-YEARS warranty from the date of delivery. This includes labour and parts free of charge for INSTRUMENTS THAT ARE DELIVERED TO THE SELLER'S MAIN OFFICE and applies only if the breakdown is NOT attributable to the purchaser (for example, due to improper use) and is NOT attributable to the...
