USER MANUAL
WEIGHT INDICATOR
E-LW: SOFTWARE FOR CONTINUOUS DOSAGE IN
UNLOADING WITH FLOW ADJUSTMENT
3590EXT and CPWE series indicator
E-LW_01_14.03_EN_U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3590EXT Series and is the answer not in the manual?

Questions and answers

Related Manuals for Dini Argeo 3590EXT Series

Summary of Contents for Dini Argeo 3590EXT Series

  • Page 1 USER MANUAL WEIGHT INDICATOR E-LW: SOFTWARE FOR CONTINUOUS DOSAGE IN UNLOADING WITH FLOW ADJUSTMENT 3590EXT and CPWE series indicator E-LW_01_14.03_EN_U...

  • Page 2: Table Of Contents

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U INDEX 1. INTRODUCTION ................................. 4 2. MAIN TECHNICAL SPECIFICATIONS ..........................5 2.1 ACCESSORIES AVAILABLE ............................6 2.2 SYMBOLS ..................................6 3. INSTALLATION .................................. 7 3.1 CPWE DRILLING TEMPLATE, CASE AND DIMENSION .................... 7 3.2 3590E CASE AND DIMENSIONS ..........................8 3.3 POWER SUPPLY .................................
  • Page 3 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.1.1.3 START UPON START-UP ......................32 12.1.2 PAUSE – MOMENTARY INTERRUPTION OF THE DOSAGE CYCLE ............32 12.1.2.1 PAUSE THROUGH EXTERNAL INPUT ..................32 12.1.2.2 PAUSE THROUGH A CONFIGURABLE KEY ................32 12.1.3 DOSAGE CYCLE END MODE ........................32 12.1.3.1 DOSAGE END BY WEIGHT (DOSAGE TARGET) ................
  • Page 4 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 15.4.3 INSTABILITY ..............................45 15.4.4 DOSAGE ............................... 46 15.4.5 DOSAGE TARGET ............................46 15.4.6 PAUSE ................................46 15.4.7 MAX.FL.R AND MIN.FL.R ..........................46 15.4.8 ALARM ................................46 15.4.9 LOCK ................................46 15.4.10 WEIGHT PULSE ............................46 15.4.11 FILLING ENABLED .............................

  • Page 5: Introduction

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 1. INTRODUCTION This manual was created to help you install and learn all about the functional possibilities of the purchased indicator. The instrument is suitable for use in various weighing environments. Not only does it have all the normal features of high-precision scales, but it also gives you the possibility to work in specific environments due to the functioning modes contained in the software implemented in the FLASH MEMORY on the internal board;...

  • Page 6: Main Technical Specifications

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 2. MAIN TECHNICAL SPECIFICATIONS 3590E: - 12 Vdc (8 ÷ 36 Vdc in the IO version) with internal 100 ÷ 240 Vac (50÷60 Hz) / 12 Vdc power adapter. POWER SUPPLY -6 Vdc with internal rechargeable battery, depending on the model CPWE: - 8 ÷...

  • Page 7: Accessories Available

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 2.1 ACCESSORIES AVAILABLE The indicator can be implemented with additional internal and external modules used to increase interfacing possibilities. For example one can connect various types of printers (in order to have an outcome of the weighs carried out). Also, one can connect a PC temporarily in order to simply program the instrument through Dinitools™, or permanently in order to have a complete management of the weighs.

  • Page 8: Installation

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 3. INSTALLATION 3.1 CPWE DRILLING TEMPLATE, CASE AND DIMENSION The weight indicator has an anodized aluminium case, whose external dimensions are shown in the figure 1. It should be mounted on a panel board respecting the safety norms. DRILLING TEMPLATE DIMENSION: 187,5mm x 91,5mm Figure 1:...

  • Page 9: 3590E Case And Dimensions

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 3.2 3590E CASE AND DIMENSIONS STAINLESS STEEL MODEL The indicator has an STAINLESS STEEL case, whose external dimensions are shown in the Figure 2. It can be simply put on a table or fixed to a shelf or column available on request. NOTE: If the identification plate is supplied separately (therefore not attached to the indicator), it is advisable to attach it to the indicator, in order to be able to identify the instrument.

  • Page 10: Power Supply

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 3.3 POWER SUPPLY ÷ - The 3590E indicator is powered with 12Vdc voltage, through an internal adapter which converts the 100 240Vac, 50÷60Hz mains voltage. TO POWER the instrument through the 240 Vac mains, insert the plug and the adapter to the 240 Vac mains socket. - The CPWE indicator is powered with 8÷36 Vdc voltage.
  • Page 11 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U DISEGNI SOPRA AGGIUNTI Figure 5 – Measures and dimensions in mm 1/2) Avaible for load cells / serial lines / inputs / outputs 3) Power input. 4) RJ45 connector.

  • Page 12: Start Up

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 3.5 START UP TO TURN ON the 3590E press the C key until the display turn on; then release. The CPWE instead is automatically turned on as soon as it is powered. The display shows: - initially a welcome message (settable in the TECHNICAL SET-UP, <<...

  • Page 13: Function Panel Keys

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 4. FUNCTION PANEL KEYS CPWE: 3590EXT:...

  • Page 14: Function Of The Keys

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 4.1 FUNCTION OF THE KEYS In the following section, and later on in the manual, the keys’ functioning is described in accordance to how these are configured by factory. It is possible to customise the functionality of the keys through the << F.KEYS >> step. FUNCTION - If pressed at length turns the instrument on/off.

  • Page 15: 2Ndf" Key: Second Function Of The Keys

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U - Entry of digits or characters. NUMERIC - While weighing, these enter a numeric value with which it’s possible to: KEYBOARD It executes calculations, and sums or subtractions the result from the current tare (see section CALCULATOR).

  • Page 16: Disabling The Keyboard

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 4.4 DISABLING THE KEYBOARD It is possible to disable the all keyboard functions (except the C key for turning on and off), in order to avoid undesired pressings of the scale keys: To lock the keyboard, press at length the F1 key: the display shows the “LoCK” message for a few instants. Now the keyboard is LOCKED: if one presses a key, the display shows for a few instants the “HOLD F1 TO UNLOCK”...

  • Page 17: Remote Control (3590Ext Version)

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U F1, F2….F10 F1,F2….F10 keys. 2ndF key TARE key. NOTE: through the remote keyboard, it’s not possible to carry out the functions made by pressing the keys at length. 4.7 REMOTE CONTROL (3590EXT VERSION) Depending on the model of indicator, it is possible to remotely control the instrument through one of the following types of remote controls: 18-key infrared (ir) or 6-key radio (rd).
  • Page 18 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U EXAMPLE OF CONFIGURATION USE OF MORE REMOTE CONTROLS WITH ONLY ONE INDICATOR If one works with only an indicator, it is possible to use any 6-key remote control, without combining it to the indicator, therefore without limiting the number of usable remote controls. To enable this mode one has to first select “RD 6 BR”...

  • Page 19: Display Functions

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 5. DISPLAY FUNCTIONS During the weighing the displays are subdivided mainly in 4 sections, shown in the figure below: 1) SELECTABLE WEIGHT DATA: WEIGHT or FLOW RATE, see section “MODIFICATION OF THE WEIGHT DATA” for the selection mode. 2) STATUS INDICATORS (led pilot lights /or graphic symbols) 3) SYSTEM STATUS INFO (on CPWE this line is shown when not in weight zoom, described in the following section): see section “SYSTEM STATUS INFO”...

  • Page 20: Status Indicators

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U In dosage: CPWE display Through the << ZOOM.W >> step, it is possible to enable/disable the function and set a time which determines the activation. When the time is set equal to 0 the function is always actives, if is set a time different to zero, the function is enabled when the keyboard isn’t used for this time.

  • Page 21: Battery Level Indication

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U SYMBOL ON LCD DISPLAY FUNCTION The weight detected by the weighing system is near the zero, included within the interval of –1/4 and +1/4 of the scale division. The weight is unstable. The displayed weight is a GROSS WEIGHT (depending on the software language). t / h The displayed digit is Flow-rate.

  • Page 22: Modification Of The Weight Data

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 5.3 MODIFICATION OF THE WEIGHT DATA While weighing, the display can show 2 types of weight data: flow-rate or gross weight. By pressing 2ndF + F8 one can switch from one type of visualization to the other one. 3590E DISABLED P .

  • Page 23: Modification Of The Displayed Info

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U CPWE kg /h - Flow-rate DISABLED 2ndF 2ndF - Gross weight DISABLED 5.4 MODIFICATION OF THE DISPLAYED INFO The data shown on the display can be modified by selecting one of the various visualisations provided for by the indicator. 5.4.1 3590E The selectable info are shown on the second line of the LCD display;...

  • Page 24: Cpwe

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U By linking the function to a direct key, see the << F.KEYS >> step, it is possible to: change the visualization also during the dosage; out of the dosage, quickly recall a visualisation by digit, with the numeric keyboard, the relative number and pressing the key linked to the function.
  • Page 25 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U VISUALISATION WITH ACTIVE FLOW-RATE ZOOM The selectable info are shown on the single line under the “Weight”/ “Flow rate” section; by pressing the F10 key (both during and out of the dosage), one will scroll through the following visualisations in this order: SECOND LINE NUM.

  • Page 26: System Status Info

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 5.5 SYSTEM STATUS INFO Below there are the statuses shown on the display on the first line or the single line in the case of active zoom on CPWE. MESSAGE DESCRIPTION The DOSAGE START input is OPEN. Also in this status, with flow greater than the DISABLED minimum, the instrument totalises the weight in transit, but the error checks are not active.

  • Page 27: Multirange Function

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U AT START-UP MESSAGE DESCRIPTION The converter points are less than the instrument’s internal divisions; one must execute a Err – 37 TECHNICAL DEFAULT (<<Dflt.t>> step of the SET-UP environment) and carefully carry out alternated with no.CAL the calibration.

  • Page 28: Display Of Metric Data (Info)

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 7. DISPLAY OF METRIC DATA (inFO) The indicator is fitted with a function named “INFO”, thanks to which it is possible to view the configuration metric data: First range capacity, first range division. Second range capacity, second range division. Third range capacity, third range division.

  • Page 29: Articles Database

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 9. ARTICLES DATABASE The indicator has a database in which it is possible to store up to 100 articles having five descriptions of 20 characters, hourly flow target, weight dosage target and initial value analogue output; each article is linked to a storage number, from 0 to 99.

  • Page 30: Cancellation

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 9.3 CANCELLATION 1) Press the F1 key to enter in the article database. 2) Select the storage to be cancelled by using the arrow keys   (or with the keyboard type the storage number; the LCD display shows the first corresponding DESCRIPTION line) and press F3.

  • Page 31: Database Access Password

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 10 DATABASE ACCESS PASSWORD In the SETUP (<<dtb.PWD>> step) one can set a password for access to the database of the articles. A password will be required only when one wants to insert, modify or delete an element of the file; for a moment the display shows the message “USER-PRESS KEY”;...

  • Page 32: Functioning Of The Dosage

    3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12 FUNCTIONING OF THE DOSAGE The programme has been made to manage the measurement/integration of the weight, flow of material that is unloaded with memorisation of the quantity of dosed material, and to adjust the flow through the 16 bit analogue output and PID control.
  • Page 33 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.1.1.3 START UPON START-UP If one of the inputs has not been linked to the “ON/OFF” function (DOSAGE START/STOP) and to the “CONSENSUS” function, the dosage automatically starts right after the turn-on cycle of the instrument and it’s possible to stop it by removing the power supply.
  • Page 34 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.1.3.3 MANUAL DOSAGE END / DOSAGE CYCLE DISABLING By setting a target weight and a target time equal to zero, the dosage continues until the dosage cycle is manually disabled. In this and in any case, it is possible to manually end/disable the cycle: By disabling the input linked to the START/STOP function, - Through the function 307 combinable with the desired key (<<...
  • Page 35 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U - Totalisation of the dosed weight; - Display of the accumulated totals; - Manual dosage cycle end or automatic (by weight or by time); - Printing of the dosage data, programmable; - Transmission of the dosed weight through an output (impulse counter); - Checking the minimum/maximum weight.
  • Page 36 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U otherwise when the dosage ends (manually or automatically by weight/time), the partial total is automatically cleared with the following dosage start. 12.3.2.1 DISPLAY OF THE ACCUMULATED TOTALS DURING THE DOSAGE The display shows also the status of the system and a second line with selectable information. By changing the available visualization it will be possible to display the various level of totals (Partial total, general total, article total).
  • Page 37 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.3.4 CHECKING THE MINIMUM/MAXIMUM WEIGHT One can control if the weight on the weighing zone is within the maximum and minimum weight set in the SETUP (<<MAX.WEI>> and <<MIN.WEI>>, TECH.MAN.REF. steps); when the weight is out of the tolerance field the indicator enters the alarm status, enabling the relative output and then in the block status, after the relative weight alarm and weight block delay times (<<ALARM>>...
  • Page 38 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.3.6 FLIGHT MATERIAL AT END OF DOSAGE It’s possible to set a FLIGHT weight, in other words, the quantity of material which, by inertia, is normally added to the dosage when it is stopped, in order to stop previously the dosage and reach correctly the set target, if one is working on it. The function foresees that the instrument stop the dosage (analogue output and output liked to the STOP function) in the moment in which the TARGET minus the MATERIAL WEIGHT IN FLIGHT is reached.
  • Page 39 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U technical manual for the configuration. 12.4.1.1 ANALOGUE OUTPUT PROPORTIONAL TO THE INSTANTANEOUS HOURLY FLOW By setting a value equal to 0 in the <<MAN.SPD>> step (TECH.MAN.REF.) the analogue output supplies a signal depending on the hourly flow value shown on the display; this signal is proportional to the maximum hourly flow, entered in the <<MAX.F.R.>>...
  • Page 40 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U LOWER FLOW outputs (if configured), connectable to external devices for control and eventual correction, when the instantaneous flow goes respectively over the Target flow + the set percentage or under the Target flow - the set percentage.
  • Page 41 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 12.5.5 FILTER ON THE HOURLY FLOW VISUALIZATION If required, it is possible to enable a filter on the hourly flow visualization in order to make it more stable, see the << F.R.VIS. >> step of the technical setup for further details, TECH.MAN.REF. 13 PRINTOUTS The instrument is fitted with different print functions, which may be used while weighing, and of 30 print formats, in other words, 30 different memory storages, each of which contain a programmable printout.
  • Page 42 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U AUTOMATIC DOSAGE END - Programmable printout - The linked format is automatically printed at the end of dosage. SYSTEM BLOCK - Programmable printout - The linked format is automatically printed when system go into the block status. MANUAL DOSAGE STOP - Programmable printout - The linked format is automatically printed when dosage go into the stop phase.
  • Page 43 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U The instrument is fitted with 30 print formats, in other words, 30 different storages, each of which contain a programmable printout. The formats are programmable in the SEtuP >> SEriAL >> Prn.FMt step in the SET-UP environment (TECH.MAN.REF.). It’s possible to quickly link to each print functions listed in the table to a stored format;...
  • Page 44 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 13.2.2 TICKET PROGRESSIVE Through function 401, combinable with the desired key (<< F.KEYS >> step, TECH.MAN.REF.), it’s possible to modify or clear the TICKET PROGRESSIVE. The TICKET PROGRESSIVE is a progressive number which increments of one at every PARTIAL TOTAL clearing. 13.2.3 LOT PROGRESSIVE Through function 403, combinable with the desired key (<<...
  • Page 45 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 15. OTHER FUNCTIONS 15.1CALCULATOR Through function 114 combinable with the desired key (<< F.KEYS >> step, TECH.MAN.REF.), one enables the calculator function.  ADDITION  MULTIPLICATION  SUBTRACTION Procedure: Enter the first value using the numerical keyboard. Press F1 to add, F2 to multiply, F3 to subtract the value.
  • Page 46 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 15.4.1 SETPOINT ON THE GROSS WEIGHT Functioning with hysteresis (rL.iSt “HYSTERESIS” parameter set as iSt.on) By selecting this functioning mode the relays function on the GROSS weight is activated; one enters two SETPOINTS for each relay: a DISABLING one, which, when the gross weight is lower than it, disables the appropriate relay; an ENABLING one, which, when the gross weight is greater or equal than it, it enables the appropriate relay.
  • Page 47 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 15.4.4 DOSAGE By selecting this functioning mode the output is enabled when the dosage is started and it is disabled when the dosage ends (see section 13.1). 15.4.5 DOSAGE TARGET By selecting this functioning mode the output is enabled when the totalised weight reaches the value set for the dosage end by weight, therefore after the dosage end.
  • Page 48 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U 15.5 DIAGNOSTIC PERIPHERALS Through function 118 combinable with the desired key (<< F.KEYS >> step, TECH.MAN.REF.), one enables the diagnostic peripherals function. The display shows: A.O. 10.000 kg STATUS DESCRIPTION 0.000 kg ANALOGIC OUTPUT(A.O) Analogue output value express in percent. OUTPUTS (OUT) Status output, non active ( ) or active ( INPUTS (IN)
  • Page 49 3590EXTLWBCIO, CPWELW series indicator E-LW_01_14.03_EN_U DECLARATION OF CONFORMITY This device conforms to the essential standards and norms relative to the applicable European regulations. The Declaration of conformity is available in the web site www.diniargeo.com. WARRANTY The TWO-YEAR warranty period begins on the day the instrument is delivered. It includes spare parts and labour for repairs at no charge if the INSTRUMENTS ARE RETURNED prepaid to the DEALER’S PLACE OF BUSINESS.
